System And Components
245-2808 SENSOR GP-SPEED -TRANSMISSIONS/N M1R1-2062
Group No: 245-2808 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1B3867 | 1 BALL BEARING | 1 | |
| 6T5611 | 2 SPACER (9.75X17.5X16.25-MM THK) | 5 | |
| 6T5612 | 3 GROMMET | 5 | |
| 6T5613 | 4 SPACER (7.85-MM THK) | 1 | |
| 9W7406 | 5 SHAFT | 1 | |
| 1171385 | 6 SEAL-O-RING | 2 | |
| 1481507 | 7 ROTOR-SENSOR | 1 | |
| 2016615 | 8 SENSOR GP-SPEED (TRANSMISSION) | 2 | |
| 2032060 | 9 RETAINER-BEARING | 1 | |
| 2580771 | 10 GUARD AS | 1 | |
| 2580953 | 11 HOUSING | 1 | |
| 0L1351 | 12 BOLT (3/8-16X0.875-IN) | 3 | |
| 1305300 | 13 CLIP | 2 | |
| 2A4639 | 14 BOLT (3/8-16X1.625-IN) | 2 | |
| 2H3755 | 15 BOLT (5/16-18X0.43-IN) | 2 | |
| 2S6160 | 16 WASHER-HARD (10.2X32X5-MM THK) | 5 | |
| 3B1915 | 17 BOLT (3/8-16X1.375-IN) | 3 | |
| 4P8134 | 18 CLIP (LADDER) | 2 | |
| 5M2894 | 19 WASHER-HARD (10.2X18.5X2.5-MM THK) | 3 | |
| 5P0537 | 20 WASHER-HARD (7.2X14.5X2-MM THK) | 4 | |
| 7K1181 | 21 STRAP-CABLE | 2 | |
| 8H3128 | 22 BOLT-SOCKET HEAD (1/4-20X0.625-IN) | 4 | |
| 8H3981 | 23 RING-RETAINING | 1 |
