System And Components
Assembly
100%

245-2808 SENSOR GP-SPEED -TRANSMISSIONS/N M1R2482-UP

Group No: 245-2808 · Commonality
Part NumberPart NameQty
1B38671 BALL BEARING1
6T56112 SPACER (9.75X17.5X16.25-MM THK)5
6T56123 GROMMET5
6T56134 SPACER (7.85-MM THK)1
9W74065 SHAFT1
20339406 SEAL-O-RING2
14815077 ROTOR-SENSOR1
20166158 SENSOR GP-SPEED (TRANSMISSION)2
203206010 RETAINER-BEARING1
475742411 GUARD AS1
1F0750NUT-WELD (3/8-16-THD)1
258095312 HOUSING1
0L135113 BOLT (3/8-16X0.875-IN)3
130530014 CLIP2
2A463915 BOLT (3/8-16X1.625-IN)2
2H375516 BOLT (5/16-18X0.43-IN)2
2S616017 WASHER-HARD (10.2X32X5-MM THK)5
3B191518 BOLT (3/8-16X1.375-IN)3
5M289419 WASHER-HARD (10.2X18.5X2.5-MM THK)3
5P053720 WASHER-HARD (7.2X14.5X2-MM THK)4
8H312821 BOLT-SOCKET HEAD (1/4-20X0.625-IN)4
8H398122 RING-RETAINING1
4P813423 CLIP (LADDER)2
7K118124 STRAP-CABLE2
