System And Components
228-6983 WIRING GP-POWER TRAINS/N DBB706-UP
Group No: 228-6983 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 4 | |
| 7K1181 | 2 STRAP-CABLE | 4 | |
| 7T0266 | 3 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 9L1775 | 4 BRACKET | 1 | |
| 9L6331 | 5 BRACKET | 2 | |
| 2745147 | 7 PLATE AS | 1 | |
| 3417982 | 8 HARNESS AS-TRANSMISSION | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 1028801 | KIT-RECEPTACLE (12-PIN) | 3 | |
| 6D8149 | PLUG AS-CONNECTOR (10-PIN) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 32 | |
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 20-GA) | 13 | |
| 8T8737 | PLUG-SEAL | 38 | |
| 9X1343 | RECEPTACLE AS-CONNECTOR (40-PIN) | 1 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 36 | |
| 9X3402 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 4 | |
| 1148843 | SLEEVE-PLASTIC (180-CM) | ||
| 1148844 | SLEEVE-PLASTIC (80-CM) | ||
| 1193662 | TUBE-HEAT SHRINK (10.85-MM DIA)(13-CM) | ||
| 1257875 | TUBE-HEAT SHRINK (7.44-MM DIA)(30-CM) | ||
| 1552255 | KIT-CONNECTING PLUG (12-PIN) | 2 | |
| 1552260 | KIT-CONNECTING PLUG (3-PIN) | 2 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 6 | |
| 1690585 | WIRE AS | 1 | |
| 1H4393 | 9 LOCKWASHER | 4 | |
| 1305300 | 10 CLIP | 5 | |
| 1325789 | 11 CLIP (LADDER) | 3 | |
| 2196485 | 12 LAMP GP-FLOOD (24-VOLT) | 1 | |
| 4K8864 | 13 CLIP (LOOP) | 3 | |
| 4L6454 | 14 BOLT (3/8-16X1-IN) | 3 | |
| 4P7581 | 15 CLIP (LADDER) | 4 | |
| 4P8134 | 16 CLIP (LADDER) | 1 | |
| 4S1962 | 17 CLIP (LOOP) | 1 | |
| 5M3062 | 18 BOLT (3/8-16X0.75-IN) | 1 | |
| 5P9297 | 20 CLIP (LOOP) | 1 | |
| 5S7379 | 21 BOLT (3/8-16X0.875-IN) | 1 | |
| 6D4246 | 22 CLIP (LOOP) | 1 | |
| 6V8801 | 24 NUT (3/8-16-THD) | 4 | |
| 8M2770 | 25 CLIP (LOOP) | 1 | |
| 8T4896 | 27 WASHER-HARD (10.2X18.5X2.5-MM THK) | 23 | |
| 8T9405 | 28 BOLT-SOCKET HEAD (M4X0.7X16-MM) | 4 | |
| 5P6029 | 29 LOCKWIRE (0.2-M) |
