System And Components
9W-4119 ACTUATOR GP-ROTARYS/N M1R1-UP
Group No: 9W-4119 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8E8440 | 1 BODY AS-ACTUATOR | 1 | |
| 8E8439 | 1A DOWEL | 2 | |
| 5P9400 | 1B BEARING-ROLLER | 1 | |
| 9W4118 | 2 ROTOR AS-ACTUATOR | 1 | |
| 5P7590 | BOLT-SOCKET HEAD (6-32X0.75) | 5 | |
| 9G9440 | 3 VANE-ACTUATOR | 1 | |
| 5D4697 | 4 BOLT-12 POINT HEAD (1/4-20X1-IN) | 2 | |
| 9W4116 | 5 COVER AS | 1 | |
| 5P9400 | 5A BEARING-ROLLER | 1 | |
| 1B9575 | 6 BOLT (5/16-18X1.56-IN) | 2 | |
| 9W6964 | 7 VALVE AS-EXHAUST (UPSHIFT PRESSURE SIGNAL) | 1 | |
| 9W6964 | 7A VALVE AS-EXHAUST (DOWNSHIFT PRESSURE SIGNAL) | 1 | |
| 8N4173 | DOWEL | 1 | |
| 3E4354 | BALL | 1 | |
| 1J9671 | 8 SEAL-O-RING | 2 | |
| 9S6155 | 9 PLUG AS | 2 | |
| 6J4694 | PLUG | 1 | |
| 4H8380 | 9A PIN-SPRING | 1 | |
| 9M1974 | 10 WASHER-HARD (8.8X16X2-MM THK) | 2 |
