System And Components
9W-2419 CASE & PARTS GP-PLANETARYS/N M1R1-UP
Group No: 9W-2419 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9W3409 | 1 CASE AS | 1 | |
| 3196231 | 2 PLUG AS | 1 | |
| 9S4183 | PLUG (1-1/16-12-THD) | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 2P7917 | 4 BAFFLE AS | 1 | |
| 0S0509 | 6 BOLT (3/8-16X0.75-IN) | 22 | |
| 5M2894 | 7 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 8M4390 | 9 SEAL-O-RING | 2 | |
| 5K9107 | 10 BOLT-LOCKING (3/8-16X0.75-IN) | 4 | |
| 8M4443 | 11 SEAL-O-RING | 2 | |
| 1S9799 | 12 SEAL-O-RING | 2 | |
| 1833407 | 13 PLUG AS | 2 | |
| 9S8004 | PLUG (9/16-18-THD) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3309770 | 14 PLUG AS | 1 | |
| 5P4483 | PLUG | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 6V8801 | 15 NUT (3/8-16-THD) | 13 | |
| 6T6064 | 16 MANIFOLD | 1 | |
| 2M3403 | 17 BOLT (3/8-16X3.63-IN) | 1 | |
| 7G1593 | 20 COVER | 1 | |
| 7G1594 | 21 GASKET | 1 | |
| 0S1589 | 22 BOLT (5/8-11X1.75-IN) | 1 | |
| 9W3411 | 23 COVER AS | 1 | |
| 7M7794 | STUD-WELD (9.4X21.5X25.5-MM) | 10 | |
| 9W3465 | 24 GASKET | 1 | |
| 3133492 | 25 PLUG AS | 1 | |
| 9S4190 | PLUG-O-RING (7/8-14-THD) | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 6T7061 | 26 EYE-LIFTING | 1 | |
| 9M4849 | 27 SEAL-O-RING | 1 |
