System And Components
9W-2429 CONTROL GP-TRANSMISSION HYDS/N M1R1365-2247
Group No: 9W-2429 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2167176 | 1 VALVE GP-TRANSMISSION CONTROL | 1 | |
| 1P3230 | 2 MANIFOLD-END | 1 | |
| 0T0573 | 3 BOLT (3/8-16X2.75-IN) | 3 | |
| 3T0919 | 4 SLEEVE | 1 | |
| 6V4365 | 5 SEAL-O-RING | 6 | |
| 3T0918 | 6 SLEEVE | 2 | |
| 1305300 | 8 CLIP | 2 | |
| 7G9475 | 9 SLEEVE | 2 | |
| 5P8118 | 10 SEAL-O-RING | 8 | |
| 0S1594 | 11 BOLT (3/8-16X1-IN) | 6 | |
| 8T4896 | 12 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 3218641 | 13 PLUG AS | 10 | |
| 9S8001 | PLUG (5/16-24-THD) | 1 | |
| 2385078 | SEAL-O-RING | 1 | |
| 0L1351 | 15 BOLT (3/8-16X0.875-IN) | 2 | |
| 2S6160 | 16 WASHER-HARD (10.2X32X5-MM THK) | 4 | |
| 2381034 | 17 GUARD | 1 | |
| 3159842 | 18 PLUG AS | 1 | |
| 6Y0789 | PLUG | 1 | |
| 2284947 | SEAL-O-RING | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 1A2029 | 21 BOLT (3/8-16X1.125-IN) | 2 | |
| 1H5514 | 22 BOLT (5/16-18X1.625-IN) | 2 | |
| 3T2720 | 23 ELBOW | 1 | |
| 0618561 | 24 SEAL-O-RING | 1 | |
| 5F6044 | 25 BOLT (3/8-16X9-IN) | 2 | |
| 5M2894 | 26 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 0619458 | 27 SEAL-O-RING | 6 | |
| 9W3549 | 28 SLEEVE | 1 | |
| 9W3548 | 29 SLEEVE | 6 | |
| 5P3456 | 30 SEAL-O-RING | 12 | |
| 1S5550 | 31 SLEEVE | 1 | |
| 9W3547 | 32 SLEEVE | 1 | |
| 3P0647 | 33 SEAL-O-RING | 2 | |
| 0L2070 | 34 BOLT (3/8-16X2.25-IN) | 4 | |
| 3023813 | 35 VALVE GP-SOLENOID (UPSHIFT, DOWNSHIFT) | 2 | |
| 8C9987 | WASHER (8.3X28X2.5-MM THK) | 1 | |
| 1110343 | LOCKNUT (5/16-18-THD) | 1 | |
| 2189894 | COIL AS (24-VOLT) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 1S9593 | STRAP-CABLE | 2 | |
| 1863735 | PIN-CONNECTOR (16-GA TO 18-GA) | 2 | |
| 8S5575 | 36 SEAL-LIP TYPE | 1 | |
| 6Y9850 | 37 COUPLING AS | 1 | |
| 7S5757 | 38 RING-RETAINING | 1 | |
| 6V3683 | 39 SEAL-O-RING | 1 | |
| 2160280 | 40 SENSOR GP-POSITION (TRANSMISSION SPEED) | 1 | |
| 0S0509 | 41 BOLT (3/8-16X0.75-IN) | 2 | |
| 3D4197 | 42 COVER | 1 | |
| 1209288 | 43 HARNESS AS-TRANSMISSION | 1 | |
| 5S3657 | RECEPTACLE AS-CONNECTOR (10-PIN) | 1 | |
| 3P1155 | 44 SEAL-O-RING | 1 | |
| 9U9714 | 45 MANIFOLD AS | 1 | |
| 5P7661 | BEARING AS-NEEDLE | 1 | |
| 1535503 | 46 GUARD | 1 | |
| 0S1617 | 47 BOLT (5/16-18X0.75-IN) | 6 | |
| 0S1619 | 48 BOLT (3/8-16X3-IN) | 2 | |
| 6T5132 | 49 COVER | 1 | |
| 6T5133 | 50 GASKET | 1 | |
| 6V0852 | 51 CAP-DUST | 1 | |
| 1645567 | 52 COUPLER AS-QUICK DISCONNECT (MALE) | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3159840 | 54 ELBOW AS | 1 | |
| 6V8077 | ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1833407 | 55 PLUG AS | 1 | |
| 9S8004 | PLUG (9/16-18-THD) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 5P6718 | 56 SEAL-O-RING | 5 | |
| 3072673 | 57 PLUG AS | 5 | |
| 9S8005 | PLUG (3/4-16-THD) | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 1004083 | KIT-SEAL | 1 |
