System And Components
236-0799 LINES GP-POWER TRAIN OILS/N DBB1-314
Group No: 236-0799 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1N8559 | 1 TEE-SERVICE | 1 | |
| 6G0078 | 2 BREATHER (TRANSMISSION) | 2 | |
| 6V0852 | 3 CAP-DUST | 2 | |
| 8C3447 | 4 CAP-DUST | 1 | |
| 8W2399 | 5 HOSE AS | 1 | |
| 1645567 | 6 COUPLER AS-QUICK DISCONNECT (MALE) | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 1645590 | 7 VALVE AS-FLUID SAMPLING | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 8C3446 | VALVE-SAMPLING | 1 | |
| 2400013 | 8 HOSE AS | 1 | |
| 2400014 | 9 HOSE AS | 1 | |
| 2400016 | 10 HOSE AS | 1 | |
| 2400015 | 11 HOSE AS | 1 | |
| 2512453 | 12 TUBE AS | 1 | |
| 2549168 | 13 HOSE AS | 1 | |
| 2550992 | 14 TUBE AS | 1 | |
| 2552344 | 15 HOSE AS | 1 | |
| 2558335 | 16 BRACKET | 1 | |
| 0672551 | 17 CLIP | 1 | |
| 1488305 | 18 ADAPTER AS | 1 | |
| 5P9617 | ADAPTER | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 1488319 | 19 CONNECTOR AS | 1 | |
| 6V8715 | CONNECTOR | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1488327 | 20 CONNECTOR AS | 1 | |
| 6V8637 | CONNECTOR | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488336 | 21 CONNECTOR AS | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1488347 | 22 ELBOW AS | 1 | |
| 6V9007 | ELBOW | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488361 | 23 ELBOW AS (90-DEG) | 2 | |
| 6V9200 | ELBOW | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1488367 | 24 ELBOW AS | 1 | |
| 6V9850 | ELBOW | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1488392 | 25 ELBOW AS | 1 | |
| 6V9853 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1536237 | 26 ELBOW AS | 1 | |
| 6V9004 | ELBOW | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1P3704 | 27 SEAL-RECTANGULAR | 3 | |
| 1P4577 | 28 FLANGE-HALF | 6 | |
| 1P4579 | 29 FLANGE-HALF | 4 | |
| 1P5761 | 30 FLANGE-HALF | 4 | |
| 2169199 | 31 UNION AS | 2 | |
| 9X2317 | UNION | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V8400 | SEAL-O-RING | 1 | |
| 2K3019 | 32 CLAMP-HOSE | 2 | |
| 3D2992 | 33 SEAL | 1 | |
| 3J5389 | 34 PLUG (EXTERNAL) | 1 | |
| 4J0520 | 35 SEAL-O-RING | 3 | |
| 4J0521 | 36 SEAL-O-RING | 1 | |
| 4J0524 | 37 SEAL-O-RING | 2 | |
| 5D6149 | 38 SCREEN AS (TRANSMISSION SCAVENGE) | 1 | |
| 5M3062 | 39 BOLT (3/8-16X0.75-IN) | 1 | |
| 5P1075 | 40 WASHER-HARD (10.2X22.5X3-MM THK) | 2 | |
| 5S7382 | 41 BOLT (3/8-16X1.375-IN) | 12 | |
| 5S7383 | 42 BOLT (3/8-16X1.75-IN) | 2 | |
| 5T9915 | 43 ELBOW | 1 | |
| 6G1121 | 44 ELBOW | 1 | |
| 6K4934 | 45 CLIP (SLOT) | 2 | |
| 6K4935 | 46 CLIP (TAB) | 2 | |
| 6V8801 | 47 NUT (3/8-16-THD) | 1 | |
| 6V9157 | 48 ADAPTER | 1 | |
| 6V9172 | 49 NUT (1-7/16-12-THD) | 2 | |
| 7M8485 | 50 SEAL-O-RING | 1 | |
| 7X0288 | 51 BOLT (3/8-16X1.625-IN) | 1 | |
| 7X0310 | 52 BOLT (7/16-14X2-IN) | 8 | |
| 7X0507 | 53 WASHER-HARD (12X22.5X5-MM THK) | 8 | |
| 8D8428 | 54 ADAPTER | 1 | |
| 8M2773 | 55 CLIP (LOOP) | 1 | |
| 8T2501 | 56 BOLT (3/8-16X2-IN) | 4 | |
| 8T4223 | 57 WASHER-HARD (13.5X25.5X3-MM THK) | 10 | |
| 8T4896 | 58 WASHER-HARD (10.2X18.5X2.5-MM THK) | 21 | |
| 8T8917 | 59 BOLT (1/2-13X1.25-IN) | 2 | |
| 8T8919 | 60 BOLT (1/2-13X1.75-IN) | 8 | |
| 8W2398 | 61 FLANGE | 1 | |
| 8W2521 | 62 HOSE AS | 1 | |
| 9B7237 | 63 BOLT (3/8-16X1.25-IN) | 2 | |
| 9L1480 | 64 GASKET | 1 |
