System And Components
236-0799 LINES GP-POWER TRAIN OILS/N DBB315-UP
Group No: 236-0799 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1N8559 | 1 TEE-SERVICE | 1 | |
| 4D0179 | 2 BRACKET-MOUNTING | 2 | |
| 6G0078 | 3 BREATHER (TRANSMISSION) | 2 | |
| 6V0852 | 4 CAP-DUST | 2 | |
| 8W2399 | 6 HOSE AS | 1 | |
| 8X6973 | 7 HOSE AS | 1 | |
| 8X9261 | 8 HOSE AS | 1 | |
| 1645567 | 9 COUPLER AS-QUICK DISCONNECT (MALE) | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 1880839 | 11 HOSE AS | 1 | |
| 2081629 | 12 ELBOW AS | 2 | |
| 2T2396 | ELBOW | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 2400013 | 13 HOSE AS | 1 | |
| 2400014 | 14 HOSE AS | 1 | |
| 2512453 | 15 TUBE AS | 1 | |
| 2549168 | 16 HOSE AS | 1 | |
| 2550992 | 17 TUBE AS | 1 | |
| 2552344 | 18 HOSE AS | 1 | |
| 2723185 | 19 BRACKET | 1 | |
| 2723186 | 20 HOSE AS | 1 | |
| 2723187 | 21 HOSE AS | 1 | |
| 1S6420 | 22 CLIP | 1 | |
| 1488327 | 24 CONNECTOR AS | 1 | |
| 6V8637 | CONNECTOR | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488345 | 25 CONNECTOR AS | 2 | |
| 6V8638 | CONNECTOR | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1488347 | 26 ELBOW AS | 1 | |
| 6V9007 | ELBOW | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488358 | 27 ELBOW AS | 1 | |
| 6V8624 | ELBOW | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1488361 | 28 ELBOW AS (90-DEG) | 2 | |
| 6V9200 | ELBOW | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1488370 | 29 ELBOW AS | 1 | |
| 6V9850 | ELBOW | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1488392 | 30 ELBOW AS | 1 | |
| 6V9853 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1504043 | 31 CONNECTOR AS | 1 | |
| 6V9873 | CONNECTOR | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1536237 | 32 ELBOW AS | 1 | |
| 6V9004 | ELBOW | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1654931 | 33 ELBOW AS | 1 | |
| 1P3704 | 34 SEAL-RECTANGULAR | 3 | |
| 1P4577 | 35 FLANGE-HALF | 6 | |
| 1P4579 | 36 FLANGE-HALF | 4 | |
| 1P5761 | 37 FLANGE-HALF | 4 | |
| 2169199 | 38 UNION AS | 2 | |
| 9X2317 | UNION | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V8400 | SEAL-O-RING | 1 | |
| 2B0858 | 39 PLUG-PIPE | 1 | |
| 2K3019 | 40 CLAMP-HOSE | 2 | |
| 3D2992 | 41 SEAL | 1 | |
| 4J0520 | 42 SEAL-O-RING | 3 | |
| 4J0521 | 43 SEAL-O-RING | 1 | |
| 4J0524 | 44 SEAL-O-RING | 2 | |
| 5D6149 | 45 SCREEN AS (TRANSMISSION SCAVENGE) | 1 | |
| 4L6454 | 46 BOLT (3/8-16X1-IN) | 1 | |
| 5P1075 | 47 WASHER-HARD (10.2X22.5X3-MM THK) | 2 | |
| 5S7382 | 48 BOLT (3/8-16X1.375-IN) | 12 | |
| 5S7383 | 49 BOLT (3/8-16X1.75-IN) | 2 | |
| 5T9915 | 50 ELBOW | 1 | |
| 6G1121 | 51 ELBOW | 1 | |
| 6K4934 | 52 CLIP (SLOT) | 2 | |
| 6K4935 | 53 CLIP (TAB) | 2 | |
| 6V8801 | 54 NUT (3/8-16-THD) | 1 | |
| 6V9157 | 55 ADAPTER | 3 | |
| 6V9172 | 56 NUT (1-7/16-12-THD) | 2 | |
| 7M8485 | 57 SEAL-O-RING | 1 | |
| 7X0288 | 58 BOLT (3/8-16X1.625-IN) | 1 | |
| 7X0310 | 59 BOLT (7/16-14X2-IN) | 8 | |
| 7X0507 | 60 WASHER-HARD (12X22.5X5-MM THK) | 8 | |
| 8D8428 | 61 ADAPTER | 1 | |
| 1S0994 | 62 CLIP (LOOP) | 1 | |
| 8T2501 | 63 BOLT (3/8-16X2-IN) | 4 | |
| 8T2502 | 64 BOLT (3/8-16X1.125-IN) | 4 | |
| 8T4223 | 65 WASHER-HARD (13.5X25.5X3-MM THK) | 10 | |
| 8T4896 | 66 WASHER-HARD (10.2X18.5X2.5-MM THK) | 25 | |
| 8T8917 | 67 BOLT (1/2-13X1.25-IN) | 2 | |
| 8T8919 | 68 BOLT (1/2-13X1.75-IN) | 8 | |
| 8W2398 | 69 FLANGE | 1 | |
| 9B7237 | 70 BOLT (3/8-16X1.25-IN) | 2 | |
| 9L1480 | 71 GASKET | 1 |
