System And Components
243-1610 LINES GP-RETARDERS/N DBB1-296
Group No: 243-1610 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1644216 | 1 VALVE GP-RETARDER HYD CONTROL | 1 | |
| 2432054 | 2 HOSE AS | 1 | |
| 2432055 | 3 HOSE AS | 1 | |
| 2589769 | 4 TUBE AS | 1 | |
| 2435531 | 5 HOSE AS | 1 | |
| 2437215 | 6 ELBOW | 1 | |
| 2547753 | 7 BRACKET AS | 1 | |
| 2559159 | 8 HOSE AS | 1 | |
| 2559160 | 9 HOSE AS | 1 | |
| 2559173 | 10 TUBE AS | 1 | |
| 1488347 | 11 ELBOW AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9007 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488392 | 12 ELBOW AS | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 6V9853 | ELBOW | 1 | |
| 1488411 | 13 PLUG AS | 2 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 9S4185 | PLUG (3/4-16-THD) | 1 | |
| 1536259 | 14 TEE AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8777 | TEE-FACE SEAL | 1 | |
| 6V9746 | SEAL-O-RING | 2 | |
| 1606348 | 15 HOSE AS | 1 | |
| 1P3705 | 16 SEAL-RECTANGULAR | 1 | |
| 1P4577 | 17 FLANGE-HALF | 4 | |
| 1P4578 | 18 FLANGE-HALF | 4 | |
| 1P4579 | 19 FLANGE-HALF | 4 | |
| 3J5389 | 20 PLUG (EXTERNAL) | 1 | |
| 4J0520 | 21 SEAL-O-RING | 2 | |
| 4J0522 | 22 SEAL-O-RING | 2 | |
| 4J0524 | 23 SEAL-O-RING | 3 | |
| 4K8302 | 24 CLIP (LOOP) | 1 | |
| 5H4778 | 25 ELBOW | 1 | |
| 5M3062 | 26 BOLT (3/8-16X0.75-IN) | 1 | |
| 5P1075 | 27 WASHER-HARD (10.2X22.5X3-MM THK) | 4 | |
| 5P2566 | 28 BOLT (1/2-13X1.5-IN) | 5 | |
| 5P7468 | 29 CLIP (SLOT) | 2 | |
| 5P7469 | 30 CLIP (TAB) | 2 | |
| 5P8444 | 31 GROMMET (37-MM ID) | 2 | |
| 5S7382 | 32 BOLT (3/8-16X1.375-IN) | 8 | |
| 5S7383 | 33 BOLT (3/8-16X1.75-IN) | 1 | |
| 9K7290 | 34 BOLT-12 POINT HEAD (1/2-13X3.25-IN) | 4 | |
| 6V8188 | 35 NUT (1/2-13-THD) | 1 | |
| 6V8801 | 36 NUT (3/8-16-THD) | 1 | |
| 7K1181 | 37 STRAP-CABLE | 2 | |
| 7S8920 | 38 CLIP (SLOT) | 2 | |
| 7S8921 | 39 CLIP (TAB) | 2 | |
| 7X0320 | 40 BOLT (7/16-14X5-IN) | 3 | |
| 7X0325 | 41 BOLT (1/2-13X2.5-IN) | 1 | |
| 7X0584 | 42 WASHER-HARD (13.5X20.5X2-MM THK) | 2 | |
| 8M2773 | 43 CLIP (LOOP) | 1 | |
| 8M4987 | 44 SEAL-O-RING | 2 | |
| 8M5010 | 45 SEAL-O-RING | 1 | |
| 8M5661 | 46 SEAL-O-RING | 1 | |
| 8M8281 | 47 SEAL-O-RING | 1 | |
| 8T4223 | 48 WASHER-HARD (13.5X25.5X3-MM THK) | 16 | |
| 8T4835 | 49 BOLT (1/2-13X2-IN) | 4 | |
| 8T4896 | 50 WASHER-HARD (10.2X18.5X2.5-MM THK) | 9 | |
| 8T5360 | 51 WASHER (12X22.5X2.5-MM THK) | 11 | |
| 8T8916 | 52 BOLT (7/16-14X1.5-IN) | 8 | |
| 8T8917 | 53 BOLT (1/2-13X1.25-IN) | 2 | |
| 8T8919 | 54 BOLT (1/2-13X1.75-IN) | 4 | |
| 8T9389 | 55 BOLT (1/2-13X2.75-IN) | 1 | |
| 9M7539 | 56 SEAL-O-RING | 1 |
