System And Components
1T-1065 TORQUE CONVERTER GPS/N 60T1-UP
Group No: 1T-1065 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0S1594 | 1 BOLT (3/8-16X1-IN) | 48 | |
| 1T0689 | 2 WASHER (9.93X22.22X2.54-MM THK) | 36 | |
| 1T0651 | 3 RING-RETAINING | 1 | |
| 1T1078 | 4 BEARING-THRUST | 2 | |
| 1T1079 | 5 HUB-IMPELLER | 1 | |
| 1T1085 | 6 CARRIER AS | 1 | |
| 1T0767 | 7 BUSHING | 1 | |
| 1T0649 | 8 RING-RETAINING | 1 | |
| 1T1082 | 9 HUB | 1 | |
| 9S8840 | 10 SHAFT-INPUT | 1 | |
| 1T0648 | 11 RING-METAL SEAL | 1 | |
| 1T1348 | 12 SUPPORT AS-CARRIAGE | 1 | |
| 1T1347 | 13 BUSHING | 1 | |
| 1T0704 | 14 PLATE-CLAMP | 1 | |
| 1T0657 | 15 PLATE | 2 | |
| 1T0861 | 16 IMPELLER-CONVERTER | 1 | |
| 1T0680 | 17 SPRING-FREEWHEEL | 11 | |
| 1T0679 | 18 ROLLER-FREEWHEEL | 11 | |
| 2843599 | 19 CAM-FREEWHEEL | 1 | |
| 1T0662 | 20 TURBINE-CONVERTER | 1 | |
| 1T0665 | 21 RING-CLAMP | 1 | |
| 6F7030 | 22 BOLT (3/8-24X1-IN) | 20 | |
| 0S1621 | 23 BOLT (1/2-13X1-IN) | 12 | |
| 1T0762 | 24 RACE-THRUST BEARING | 1 | |
| 1T0966 | 25 FLANGE AS | 1 | |
| 1T0647 | 26 BUSHING | 1 | |
| 2S7978 | 27 WASHER (1.406X2X0.134-IN THK) | 1 | |
| 9M1975 | 28 RING-RETAINING | 1 | |
| 3H1816 | 29 RING-RETAINING | 1 | |
| 1T0686 | 30 RACE-THRUST BEARING | 3 | |
| 1T0655 | 31 BEARING-THRUST | 2 | |
| 1495986 | 32 STATOR | 1 | |
| 1T0669 | 33 HOUSING | 1 | |
| 8B7789 | 34 RING-SNAP | 1 |
