196-7581 WHEEL & FINAL DRIVE GPS/N DBB1-UP

Group No: 196-7581 · Commonality

Part Number	Part Name	Qty
1P9593	1 CONE-BEARING (TAPERED ROLLER)	2
1P9594	2 CUP-BEARING (TAPERED ROLLER)	2
2F6067	3 RING-RETAINING	6
2G1006	4 SPACER (2.375X4.19X0.203-IN)	12
2G4553	5 PLATE	2
2G5884	6 COVER	2
2P1823	7 CUP-BEARING (TAPERED ROLLER)	2
2P1824	8 CONE-BEARING (TAPERED ROLLER)	2
3D2239	9 VALVE AS-TIRE (TIRE INFLATION)	2
6F3930	CORE-VALVE	1
9K7951	CAP-VALVE	1
3D5852	10 RING-LOCK	2
3D8418	11 SPACER (2.44X3.38X0.614-IN)	6
3F9194	12 FLANGE	4
4D0141	13 RING-RETAINING	2
4D3151	14 BEARING AS-ROLLER	12
4D3173	15 RETAINER	8
4E2133	16 GEAR-INTERNAL RING (110-TEETH)	2
4E2134	17 GEAR-SUN (19-TEETH)	2
5B3265	18 GASKET	2
5T5682	19 DRIVER	2
6B5262	20 PLUG (FINAL DRIVE)	2
6G8370	21 SHIM PACK (INCLUDES 18-SHIMS)	2
8W9595	22 BAND AS	2
8W9697	23 CARRIER-PLANETARY	2
8W9986	24 WHEEL AS	2
1B5174	PLUG-PIPE	1
2G7781	SEALANT	1
7M7410	PLUG-PIPE	1
2359767	25 RETAINER AS-SEAL	2
0S0130	PIN	1
9D8717	26 SPACER (7.979X9.75X0.82-IN)	2
9G5319	27 SEAL GP-DUO-CONE	2
1011504	28 SHAFT	6
1165311	29 SPACER (63.63X85.5X20-MM)	2
1165312	30 RING	2
1454372	31 HUB	2
1967569	32 HOUSING-AXLE	2
0308535	33 BOLT-LOCKING (3/8-16X0.875-IN)	8
0L1178	34 BOLT (3/4-10X2-IN)	44
1A8537	35 BOLT (5/8-11X2.75-IN)	12
1M9015	36 SEAL-O-RING	2
2D2444	37 SEAL-O-RING	2
3D8422	38 SEAL-O-RING	2
3K0360	39 SEAL-O-RING	2
4D1577	40 SEAL-O-RING	2
4E0403	41 GEAR-PLANETARY (44-TEETH)	6
4F2411	42 SEAL-O-RING	2
5H1504	43 WASHER-HARD (20X33.5X5-MM THK)	44
5K8454	44 BOLT (1/2-13X1.12-IN)	16
5P8247	45 WASHER-HARD (17X32X3.5-MM THK)	12
6F4855	46 SEAL-O-RING	2
8T8917	47 BOLT (1/2-13X1.25-IN)	12
2770725	48 SHAFT-AXLE (RH)	1
2770726	49 SHAFT-AXLE (LH)	1
8T4223	50 WASHER-HARD (13.5X25.5X3-MM THK)	12
8T4994	51 WASHER-HARD (20X36.5X3.5-MM THK)	44
8T9398	52 BOLT (3/4-10X1.75-IN)	44
9S8005	53 PLUG (3/4-16-THD)	2
