System And Components
228-5316 CASE & FRAME GPS/N DBB1-UP
Group No: 228-5316 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4D0306 | 1 GASKET-CAP | 1 | |
| 5T7100 | 2 GASKET | 2 | |
| 6F5188 | 3 SEAL-RING | 1 | |
| 7B0863 | 4 LATCH-PIN | 1 | |
| 7V6063 | 5 BOLT AS | 7 | |
| 8D4926 | 6 COVER | 1 | |
| 8W6111 | 7 ELBOW AS | 1 | |
| 1445374 | GAUGE-SIGHT (TRANSMISSION) | 1 | |
| 8W6112 | 8 ELBOW AS | 1 | |
| 1445374 | GAUGE-SIGHT (DIFFERENTIAL) | 1 | |
| 1181222 | 9 TUBE AS | 1 | |
| 3475705 | 10 STEP AS | 2 | |
| 1753864 | 11 PIN-DRAWBAR | 1 | |
| 1788540 | 12 PLATE AS | 1 | |
| 1F0748 | NUT-WELD (1/2-13-THD) | 2 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 2 | |
| 2301040 | 13 CASE & FRAME AS | 1 | |
| 2420293 | 13A PLATE-TREAD | 1 | |
| 2307624 | 14 BUMPER AS | 1 | |
| 2420294 | 15 PLATE-TREAD | 1 | |
| 2550967 | 16 PLATE | 1 | |
| 2722982 | 17 CAP-FILLER (TRANSMISSION) | 1 | |
| 2722983 | 18 CAP-FILLER (DIFFERENTIAL) | 1 | |
| 2949721 | 19 PLATE | 1 | |
| 1165351 | 20 RIVET | 4 | |
| 1793149 | 21 STUD-TAPERLOCK (7/8-9X2.75-IN)(7/8-9X2.75-IN) | 6 | |
| 2D5238 | 22 STUD-TAPERLOCK (5/8-11X2.5-IN) | 2 | |
| 2K4821 | 23 LOCKNUT (5/8-18-THD) | 1 | |
| 3D0490 | 24 STUD-TAPERLOCK (1/2-13X1.97-IN) | 6 | |
| 3D5963 | 25 STUD-TAPERLOCK (5/8-11X3.5-IN) | 18 | |
| 4K7463 | 26 SEAL-LIP TYPE | 2 | |
| 4L6454 | 27 BOLT (3/8-16X1-IN) | 15 | |
| 5M1932 | 28 STUD-TAPERLOCK (1/2-13X2.17-IN) | 4 | |
| 5P1075 | 29 WASHER-HARD (10.2X22.5X3-MM THK) | 6 | |
| 5P7815 | 30 SEAL-O-RING | 2 | |
| 5S3676 | 31 SEAL-O-RING | 1 | |
| 6V0439 | 32 PLUG-MAGNETIC | 2 | |
| 6V8188 | 33 NUT (1/2-13-THD) | 4 | |
| 7X0365 | 34 BOLT (3/4-10X1.5-IN) | 4 | |
| 7X3192 | 35 BOLT (5/8-18X2-IN) | 1 | |
| 8D8829 | 36 BUSHING | 2 | |
| 8J7596 | 37 BUSHING | 2 | |
| 8T4223 | 38 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T4896 | 39 WASHER-HARD (10.2X18.5X2.5-MM THK) | 9 | |
| 8T5361 | 40 WASHER-HARD (28X49X5-MM THK) | 8 | |
| 9S1363 | 41 BOLT (1-8X2.75-IN) | 8 |
