System And Components
309-1376 DOOR GP-ACCESS -TOPS/N DBB608-640
Group No: 309-1376 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6P2216 | 1 CAP (PUSH ON) | 25 | |
| 2409118 | 2 DOOR GP-ACCESS | 1 | |
| 2731895 | 3 TREAD | 1 | |
| 2731896 | 4 TREAD | 1 | |
| 2734889 | 5 LATCH AS | 1 | |
| 5C2890 | NUT (M6X1-THD) | 4 | |
| 8C3398 | LOCKWASHER | 4 | |
| 1608503 | NUT (M10X1.5-THD) | 2 | |
| 2170733 | LOCK AS | 1 | |
| 2726628 | LOCK AS-CYLINDER | 1 | |
| 2757891 | CAM | 1 | |
| 2734890 | 6 LATCH AS | 1 | |
| 5C2890 | NUT (M6X1-THD) | 4 | |
| 8C3398 | LOCKWASHER | 4 | |
| 1608503 | NUT (M10X1.5-THD) | 2 | |
| 2767643 | 7 PAWL | 2 | |
| 2837591 | 8 INSULATION | 1 | |
| 2837592 | 9 INSULATION | 1 | |
| 2837593 | 10 INSULATION | 2 | |
| 3091373 | 11 BAFFLE | 1 | |
| 3091374 | 12 PLATE | 1 | |
| 3091375 | 13 INSULATION | 1 | |
| 3091379 | 14 ANGLE | 1 | |
| 3091380 | 15 BAFFLE | 1 | |
| 3091381 | 16 PLATE | 2 | |
| 3091382 | 17 PLATE | 3 | |
| 3091383 | 18 PLATE | 1 | |
| 1393785 | 19 RIVET-POP | 18 | |
| 6C3679 | 20 RIVET-POP | 22 | |
| 6V7744 | 21 LOCKNUT (M10X1.5-THD) | 2 |
