System And Components
342-6028 DOOR GP-ACCESS -TOPS/N DBB656-UP
Group No: 342-6028 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6P2216 | 1 CAP (PUSH ON) | 25 | |
| 2884235 | 2 DOOR GP-ACCESS (TOP) | 1 | |
| 2731895 | 3 TREAD | 1 | |
| 2731896 | 4 TREAD | 1 | |
| 2837591 | 5 INSULATION | 1 | |
| 2837592 | 6 INSULATION | 1 | |
| 2837593 | 7 INSULATION | 2 | |
| 3091374 | 9 PLATE | 1 | |
| 3091375 | 10 INSULATION | 1 | |
| 3091379 | 11 ANGLE | 1 | |
| 3091380 | 12 BAFFLE | 1 | |
| 3091381 | 13 PLATE | 2 | |
| 3091382 | 14 PLATE | 3 | |
| 3091383 | 15 PLATE | 1 | |
| 3260610 | 16 LATCH AS | 2 | |
| 1H3244 | LOCKWASHER | 4 | |
| 0951207 | NUT (M12X1.75-THD) | 2 | |
| 3260612 | WASHER-TAB | 2 | |
| 3445673 | NUT (M6X1-THD) | 4 | |
| 3260614 | 17 CAM | 2 | |
| 1393785 | 18 RIVET-POP | 18 | |
| 6C3679 | 19 RIVET-POP | 22 |
