System And Components
237-4233 FENDER GPS/N DBB1-UP
Group No: 237-4233 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2A6965 | 1 PLATE | 1 | |
| 1013160 | 2 BAFFLE AS | 1 | |
| 6C3678 | RIVET | 7 | |
| 1014480 | 3 BAFFLE | 1 | |
| 2372065 | 4 BRACKET AS (RH) | 1 | |
| 2372066 | 5 BRACKET AS (LH) | 1 | |
| 2377696 | 6 PLATE | 1 | |
| 2377697 | 7 STRIP | 1 | |
| 2474315 | 8 SHIELD (LH) | 1 | |
| 2474316 | 9 SHIELD (RH) | 1 | |
| 2474317 | 10 FENDER AS (RH) | 1 | |
| 2474318 | 11 FENDER AS (LH) | 1 | |
| 2476470 | 12 CLIP AS | 1 | |
| 2V3726 | 13 BUMPER | 2 | |
| 3K6060 | 14 LOCKNUT (3/8-16-THD) | 2 | |
| 5M3062 | 15 BOLT (3/8-16X0.75-IN) | 2 | |
| 7X0772 | 16 WASHER-HARD (10.2X25.5X2.5-MM THK) | 7 | |
| 8T4897 | 17 WASHER (10.2X35X6-MM THK) | 2 | |
| 9B7237 | 18 BOLT (3/8-16X1.25-IN) | 5 |
