Assembly
100%

228-8408 HOOD GP-TRACTORS/N DBB1-263

Group No: 228-8408 · Commonality
Part NumberPart NameQty
24091101 HOOD GP-TRACTOR1
24094672 SUPPORT AS1
24094683 GRILL AS1
24239934 PLATE1
24295045 STRUT1
24295056 STRUT-LOCKING1
24338887 BLOCK-MOUNTING1
16174198 STUD (5/16-18-THD)2
19847779 WASHER-HARD (11X25X10-MM THK)8
198477810 WASHER-HARD (13.5X30X12-MM THK)4
5B318011 NUT (5/16-18-THD)2
1V736812 SPACER (0.364X0.54X1.06-IN THK)1
4L645913 BOLT (3/8-16X2.5-IN)2
4L933714 BOLT (3/8-16X1.5-IN)3
5M306215 BOLT (3/8-16X0.75-IN)12
5P107516 WASHER-HARD (10.2X22.5X3-MM THK)4
5P107617 WASHER-HARD (13.5X30X4-MM THK)2
5P256618 BOLT (1/2-13X1.5-IN)2
5S734919 BOLT (1/4-20X0.5-IN)4
5S738320 BOLT (3/8-16X1.75-IN)2
7X057521 WASHER-HARD (10.2X22.5X5-MM THK)2
7X057822 WASHER-HARD (10.2X32X2.5-MM THK)4
7X772923 WASHER (11X25X3-MM THK)3
8C443624 BOLT (1/2-13X1.375-IN)2
8T250225 BOLT (3/8-16X1.125-IN)3
8T420526 WASHER-HARD (7.2X14.5X2-MM THK)5
8T891727 BOLT (1/2-13X1.25-IN)2
9F821928 SPACER (1.25-IN THK)1
9L913229 WASHER-HARD (10.2X25.5X2.5-MM THK)1
5P564930 SEAL-BULK
