System And Components
228-8408 HOOD GP-TRACTORS/N DBB454-UP
Group No: 228-8408 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2409110 | 1 HOOD GP-TRACTOR | 1 | |
| 2409468 | 2 GRILL AS | 1 | |
| 2423993 | 3 PLATE | 1 | |
| 2526283 | 5 BLOCK-MOUNTING | 1 | |
| 3081099 | 6 STRUT | 2 | |
| 2721523 | 7 STRUT-LOCKING | 1 | |
| 2721524 | 8 SPRING | 1 | |
| 2886325 | 9 PLATE AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 4 | |
| 9F6445 | NUT-WELD (1/4-20-THD) | 2 | |
| 2940533 | 10 PIN | 2 | |
| 2940534 | 11 SUPPORT AS | 1 | |
| 5F7845 | BOSS (50.8-MM LG) | 2 | |
| 8D3508 | BOSS (3/8-16X1-IN) | 5 | |
| 1984777 | 12 WASHER-HARD (11X25X10-MM THK) | 12 | |
| 1984778 | 13 WASHER-HARD (13.5X30X12-MM THK) | 8 | |
| 1984780 | 14 WASHER-HARD (17.5X32X8-MM THK) | 10 | |
| 3B4611 | 15 PIN-COTTER | 2 | |
| 4L6454 | 16 BOLT (3/8-16X1-IN) | 3 | |
| 4M5281 | 17 BOLT (1/4-20X0.75-IN) | 4 | |
| 5M3062 | 18 BOLT (3/8-16X0.75-IN) | 22 | |
| 5P1075 | 19 WASHER-HARD (10.2X22.5X3-MM THK) | 24 | |
| 5P2566 | 21 BOLT (1/2-13X1.5-IN) | 4 | |
| 6V8801 | 22 NUT (3/8-16-THD) | 3 | |
| 6V8918 | 23 BOLT (5/16-18X1.25-IN) | 2 | |
| 7X0345 | 24 BOLT (5/8-11X1.75-IN) | 2 | |
| 7X0578 | 25 WASHER-HARD (10.2X32X2.5-MM THK) | 4 | |
| 8T4835 | 26 BOLT (1/2-13X2-IN) | 2 | |
| 8T2502 | 27 BOLT (3/8-16X1.125-IN) | 4 | |
| 8T4205 | 28 WASHER-HARD (7.2X14.5X2-MM THK) | 4 | |
| 8T4224 | 29 WASHER-HARD (8.8X16X2-MM THK) | 7 | |
| 8T6871 | 30 BOLT (5/8-11X2.5-IN) | 3 | |
| 8T9396 | 32 BOLT (5/8-11X3.25-IN) | 2 | |
| 9B7237 | 33 BOLT (3/8-16X1.25-IN) | 8 |
