System And Components
242-7102 LINES GP-SECONDARY STEERINGS/N DBB1-UP
Group No: 242-7102 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6V0852 | 1 CAP-DUST | 2 | |
| 8W0196 | 2 ADAPTER | 1 | |
| 8W1195 | 3 ELBOW | 1 | |
| 1488425 | 4 TEE AS | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 8T4834 | TEE-SWIVEL-ORFS | 1 | |
| 1488443 | 5 TEE AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 7X2459 | ADAPTER-TEE | 1 | |
| 1645567 | 6 COUPLER AS-QUICK DISCONNECT (MALE) | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 1767695 | 7 VALVE GP-CHECK (SECONDARY STEERING) | 2 | |
| 2207903 | 8 HOSE AS | 1 | |
| 2432480 | 9 HOSE AS | 1 | |
| 2432487 | 10 TUBE AS | 1 | |
| 2432492 | 11 HOSE AS | 1 | |
| 1488352 | 12 ELBOW AS | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V9854 | ELBOW (SWIVEL) | 1 | |
| 1488378 | 13 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8724 | ELBOW | 1 | |
| 1P3705 | 15 SEAL-RECTANGULAR | 1 | |
| 1P4577 | 16 FLANGE-HALF | 2 | |
| 1P4579 | 17 FLANGE-HALF | 4 | |
| 4J0520 | 18 SEAL-O-RING | 2 | |
| 4J0524 | 19 SEAL-O-RING | 2 | |
| 4L6459 | 20 BOLT (3/8-16X2.5-IN) | 4 | |
| 5J5793 | 21 BOLT-12 POINT HEAD (1/2-13X2-IN) | 4 | |
| 5M3062 | 22 BOLT (3/8-16X0.75-IN) | 2 | |
| 5P2424 | 23 BOLT (1/2-13X2.25-IN) | 4 | |
| 6D4246 | 24 CLIP (LOOP) | 3 | |
| 6J2680 | 25 SEAL-O-RING | 1 | |
| 7T8593 | 26 BLOCK | 1 | |
| 8T4223 | 27 WASHER-HARD (13.5X25.5X3-MM THK) | 12 | |
| 8T4896 | 28 WASHER-HARD (10.2X18.5X2.5-MM THK) | 6 | |
| 8T8919 | 29 BOLT (1/2-13X1.75-IN) | 8 |
