System And Components
3G-7232 BYPASS GP-FILTER -HYDRAULIC OILS/N DBB1-UP
Group No: 3G-7232 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2J2864 | 1 PLUG-DRAIN (HYDRAULIC FILTER BYPASS) | 1 | |
| 6F5559 | 1A SEAL-O-RING | 1 | |
| 7J2994 | 2 RETAINER | 2 | |
| 9J7195 | 3 COVER-FILTER | 1 | |
| 8T9056 | 4 BOLT (3/8-16X1.25-IN) | 1 | |
| 6H3956 | 5 PIN | 1 | |
| 7J2983 | 6 SPRING (OUTER) | 1 | |
| 8M0776 | 7 RIVET-POP | 3 | |
| 7J2987 | 8 PLATE-VALVE | 1 | |
| 7J2988 | 9 SHAFT | 1 | |
| 9T1958 | 10 HOUSING-BYPASS | 1 | |
| 3G3273 | 11 SPRING (INNER) | 1 | |
| 9T1959 | 12 RETAINER AS | 1 | |
| 5P1075 | 13 WASHER-HARD (10.2X22.5X3-MM THK) | 1 | |
| 4V6698 | 14 SPACER (10X16X16-MM THK) | 1 |
