System And Components
242-1336 CONTROL GP-TRAILING UNITS/N DBB1-575
Group No: 242-1336 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 2 | |
| 8V1677 | 2 FLANGE | 1 | |
| 8W0084 | 3 CLIP | 1 | |
| 1118429 | 4 VALVE GP-RELIEF (APRON) | 1 | |
| 1123131 | 5 ADAPTER | 1 | |
| 1388745 | 6 HOSE AS | 1 | |
| 1412298 | 7 CLAMP | 2 | |
| 1845180 | 8 TUBE AS | 1 | |
| 2309575 | 9 CLAMP | 4 | |
| 2309645 | 10 PLATE | 2 | |
| 2313851 | 11 TUBE AS | 1 | |
| 2361280 | 12 PLATE | 1 | |
| 2419642 | 13 HOSE AS | 1 | |
| 2419644 | 14 HOSE AS | 1 | |
| 2480292 | 15 TUBE AS | 1 | |
| 1412297 | 16 PLATE | 1 | |
| 1488374 | 17 ELBOW AS | 1 | |
| 6V8723 | ELBOW | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1488457 | 18 UNION AS (STRAIGHT) | 2 | |
| 6V8995 | UNION (STRAIGHT) | 1 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 1536258 | 19 CONNECTOR AS | 1 | |
| 8T5050 | CONNECTOR | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1853365 | 20 UNION AS | 1 | |
| 8T0129 | UNION | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1P3703 | 21 SEAL-RECTANGULAR | 1 | |
| 1P4579 | 22 FLANGE-HALF | 2 | |
| 1P4584 | 23 FLANGE-HALF | 2 | |
| 2419643 | 24 HOSE AS | 1 | |
| 2433355 | 25 SUPPORT AS | 1 | |
| 2433356 | 26 SUPPORT AS | 1 | |
| 2J2668 | 27 COVER-FLANGE | 1 | |
| 2T2305 | 28 ELBOW | 2 | |
| 4F7507 | 29 SEAL-O-RING | 1 | |
| 4J0524 | 30 SEAL-O-RING | 1 | |
| 5K1094 | 31 LOCKWASHER | 3 | |
| 5M3038 | 32 SEAL-O-RING | 1 | |
| 5P1076 | 33 WASHER-HARD (13.5X30X4-MM THK) | 2 | |
| 5P2566 | 34 BOLT (1/2-13X1.5-IN) | 4 | |
| 6D4636 | 35 CLIP (LOOP) | 3 | |
| 6J2680 | 36 SEAL-O-RING | 2 | |
| 6V0852 | 37 CAP-DUST | 1 | |
| 6V3966 | 38 FITTING AS | 1 | |
| 6V4432 | 39 BOLT (1/2-13X4-IN) | 4 | |
| 6V8188 | 40 NUT (1/2-13-THD) | 1 | |
| 6V8397 | 41 SEAL-O-RING | 2 | |
| 6V9169 | 42 NUT (13/16-16-THD) | 3 | |
| 7X0326 | 43 BOLT (1/2-13X3-IN) | 1 | |
| 7X0333 | 44 BOLT (1/2-13X4.75-IN) | 2 | |
| 7X0334 | 45 BOLT (1/2-13X5-IN) | 2 | |
| 7X0346 | 46 BOLT (5/8-11X2-IN) | 2 | |
| 7X0515 | 47 WASHER-HARD (17X35X5-MM THK) | 2 | |
| 8C4436 | 48 BOLT (1/2-13X1.375-IN) | 1 | |
| 8T4223 | 49 WASHER-HARD (13.5X25.5X3-MM THK) | 17 | |
| 8T4896 | 50 WASHER-HARD (10.2X18.5X2.5-MM THK) | 9 | |
| 8T7008 | 51 BOLT (3/8-16X3-IN) | 4 | |
| 8T8919 | 52 BOLT (1/2-13X1.75-IN) | 2 | |
| 8T9377 | 53 BOLT (3/8-16X2.25-IN) | 3 | |
| 8T9379 | 54 BOLT (3/8-16X4.25-IN) | 6 | |
| 8T9389 | 55 BOLT (1/2-13X2.75-IN) | 2 | |
| 9B3523 | 56 ADAPTER | 3 | |
| 9R3884 | 57 SPACER (13X20X45-MM THK) | 1 |
