System And Components
261-4475 LINES GP-CUSHION-HITCH -WITH ACCUMULATORS/N DBB1-575
Group No: 261-4475 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6G5003 | 1 BLOCK-PIVOT | 1 | |
| 7I5228 | 2 HOSE AS | 1 | |
| 1488326 | 3 CONNECTOR AS | 1 | |
| 6V9872 | CONNECTOR | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 8J0661 | 4 PLATE | 1 | |
| 8J1081 | 5 SPRING-LEAF | 1 | |
| 8W0068 | 6 HOSE AS | 1 | |
| 2763468 | 7 TUBE AS | 1 | |
| 8X9864 | 8 TUBE AS | 1 | |
| 8X9881 | 9 PLATE | 1 | |
| 8X9882 | 10 PLATE | 1 | |
| 2763469 | 11 PLATE | 1 | |
| 1645567 | 12 COUPLER AS-QUICK DISCONNECT (MALE) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 1645586 | 13 TEE AS | 1 | |
| 7X0871 | TEE | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1654931 | 15 ELBOW AS | 1 | |
| 6V8077 | ELBOW | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 2168309 | 16 CONNECTOR AS | 1 | |
| 1699763 | CONNECTOR | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 2T2378 | 17 HOSE AS | 1 | |
| 1065137 | 18 HOSE AS | 1 | |
| 2614474 | 19 VALVE & MTG GP-HYDRAULIC (CUSHION-HITCH) | 1 | |
| 1240174 | 20 CLIP (LOOP) | 1 | |
| 1488311 | 21 ADAPTER AS | 1 | |
| 8T1715 | ADAPTER | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 1488318 | 22 CONNECTOR AS | 1 | |
| 6V8634 | CONNECTOR | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1488372 | 23 ELBOW AS | 1 | |
| 6V8721 | ELBOW | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1488378 | 24 ELBOW AS | 1 | |
| 6V8724 | ELBOW | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1488380 | 25 ELBOW AS | 1 | |
| 6V8988 | ELBOW | 1 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 1P3703 | 26 SEAL-RECTANGULAR | 1 | |
| 1P4577 | 27 FLANGE-HALF | 2 | |
| 1S1015 | 28 CLIP (LOOP) | 2 | |
| 3B4617 | 29 PIN-COTTER | 2 | |
| 3D2824 | 30 SEAL-O-RING | 1 | |
| 4H9369 | 32 PIN | 1 | |
| 4J0520 | 33 SEAL-O-RING | 3 | |
| 4J0522 | 34 SEAL-O-RING | 1 | |
| 4K1540 | 35 PIN-CLEVIS | 1 | |
| 4L6454 | 36 BOLT (3/8-16X1-IN) | 2 | |
| 4L6459 | 37 BOLT (3/8-16X2.5-IN) | 4 | |
| 4L9337 | 38 BOLT (3/8-16X1.5-IN) | 2 | |
| 5K1094 | 39 LOCKWASHER | 1 | |
| 5M3062 | 40 BOLT (3/8-16X0.75-IN) | 2 | |
| 5P1075 | 41 WASHER-HARD (10.2X22.5X3-MM THK) | 4 | |
| 5P2228 | 42 BOLT (1/2-13X1-IN) | 2 | |
| 5P7464 | 43 CLIP (SLOT) | 1 | |
| 5P7465 | 44 CLIP (TAB) | 1 | |
| 5S7382 | 45 BOLT (3/8-16X1.375-IN) | 2 | |
| 5T2653 | 46 TUBE AS | 1 | |
| 6V0852 | 47 CAP-DUST | 1 | |
| 6V7359 | 48 GROMMET (25-MM ID, 37-MM OD) | 1 | |
| 6V8188 | 49 NUT (1/2-13-THD) | 2 | |
| 6V8801 | 51 NUT (3/8-16-THD) | 4 | |
| 6V9169 | 52 NUT (13/16-16-THD) | 1 | |
| 6V9746 | 53 SEAL-O-RING | 3 | |
| 7S3912 | 54 CLIP (TAB) | 1 | |
| 7S3913 | 55 CLIP (SLOT) | 1 | |
| 7X0772 | 56 WASHER-HARD (10.2X25.5X2.5-MM THK) | 2 | |
| 8C8400 | 58 ELBOW | 1 | |
| 8J7225 | 59 PLATE | 1 | |
| 8T2501 | 60 BOLT (3/8-16X2-IN) | 2 | |
| 8T4223 | 61 WASHER-HARD (13.5X25.5X3-MM THK) | 6 | |
| 8T4896 | 62 WASHER-HARD (10.2X18.5X2.5-MM THK) | 14 | |
| 8T8917 | 63 BOLT (1/2-13X1.25-IN) | 2 | |
| 8T9377 | 64 BOLT (3/8-16X2.25-IN) | 2 | |
| 8W0070 | 65 HOSE AS | 1 | |
| 8W0223 | 66 BRACKET | 1 | |
| 9B7237 | 67 BOLT (3/8-16X1.25-IN) | 2 |
