System And Components
227-8275 LINES GP-HYDRAULICS/N DBB1-UP
Group No: 227-8275 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3182538 | 1 HOSE AS | 1 | |
| 3G4005 | 2 LINK | 1 | |
| 6V0852 | 3 CAP-DUST | 1 | |
| 8W8580 | 4 FLANGE | 1 | |
| 1205274 | 5 BLOCK | 1 | |
| 1645567 | 6 COUPLER AS-QUICK DISCONNECT (MALE) | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 1648908 | 7 CONNECTOR AS | 1 | |
| 8T0077 | CONNECTOR | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1725226 | 8 HOSE AS | 1 | |
| 1849845 | 9 SCREEN AS-FILTER (HYDRAULIC LINES) | 1 | |
| 6V8625 | ELBOW | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 2033079 | 10 HOSE AS | 1 | |
| 2033080 | 11 HOSE AS | 1 | |
| 2441647 | 12 BLOCK-GAUGE | 1 | |
| 1488335 | 13 CONNECTOR AS | 1 | |
| 6V8635 | CONNECTOR | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1488365 | 14 ELBOW AS | 1 | |
| 8T6876 | ELBOW | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1488415 | 15 REDUCER AS | 1 | |
| 6V8936 | REDUCER | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1488428 | 16 TEE AS | 1 | |
| 6V8782 | TEE | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 1536241 | 17 ELBOW AS | 2 | |
| 8C8989 | ELBOW | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1P4576 | 18 FLANGE-HALF | 2 | |
| 1S0994 | 19 CLIP (LOOP) | 1 | |
| 1T0765 | 20 BOLT (3/8-16X1-IN) | 2 | |
| 2H4145 | 21 SEAL-O-RING | 1 | |
| 4J0520 | 23 SEAL-O-RING | 1 | |
| 4J5267 | 24 SEAL-O-RING | 2 | |
| 4L6454 | 25 BOLT (3/8-16X1-IN) | 2 | |
| 5M3062 | 26 BOLT (3/8-16X0.75-IN) | 1 | |
| 5P1075 | 27 WASHER-HARD (10.2X22.5X3-MM THK) | 3 | |
| 5P7464 | 28 CLIP (SLOT) | 1 | |
| 5P7465 | 29 CLIP (TAB) | 1 | |
| 5S7382 | 30 BOLT (3/8-16X1.375-IN) | 4 | |
| 6V1249 | 31 GROMMET (22-MM ID) | 1 | |
| 6V8801 | 33 NUT (3/8-16-THD) | 2 | |
| 8C3206 | 34 FLANGE-HALF | 2 | |
| 8C6362 | 35 BOLT (5/8-11X2.75-IN) | 4 | |
| 8F6974 | 36 BOLT (3/8-16X2.5-IN)(3/8-16X2.5-IN) | 4 | |
| 8T4122 | 37 WASHER-HARD (17X32X3.5-MM THK) | 4 | |
| 8T4896 | 38 WASHER-HARD (10.2X18.5X2.5-MM THK) | 13 | |
| 9L1775 | 39 BRACKET | 1 | |
| 9B7237 | 40 BOLT (3/8-16X1.25-IN) | 1 |
