System And Components
268-3450 COVER GP-ACCESSS/N DBB1-UP
Group No: 268-3450 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2036066 | 1 LATCH AS | 2 | |
| 2592216 | 2 ROD AS | 1 | |
| 2683449 | 3 COVER | 1 | |
| 2730180 | 4 CAM | 2 | |
| 2855778 | 5 INSULATION | 1 | |
| 2856073 | 6 PLATE AS | 1 | |
| 2856879 | 7 PLATE | 4 | |
| 2857366 | 8 INSULATION | 1 | |
| 4H3820 | 9 SPRING-LATCH | 1 | |
| 5P1075 | 10 WASHER-HARD (10.2X22.5X3-MM THK) | 2 | |
| 7J5925 | 11 PIN-COTTER | 1 | |
| 8T4970 | 12 BOLT (M6X1X14-MM) | 8 | |
| 9D7303 | 13 GROMMET | 2 | |
| 9X8256 | 14 WASHER (6.6X12X2-MM THK) | 8 | |
| 5P8309 | 15 SEAL (1-M) | ||
| 5P8309 | 15A SEAL (1.2-M) | ||
| 9X2092 | 16 TRIM-EDGE (42-CM) | ||
| 9X2092 | 16A TRIM-EDGE (40-CM) |
