System And Components
316-1740 COVER GP-ACCESS -HVACS/N DBB580-UP
Group No: 316-1740 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9M5732 | 1 RIVET-POP | 8 | |
| 3072427 | 2 PLATE AS | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 3817251 | 3 DOOR AS-ACCESS | 1 | |
| 1882702 | LATCH AS | 1 | |
| 3078323 | HINGE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 5 | |
| 3161213 | 4 TUBE AS | 1 | |
| 3817246 | 5 COVER AS | 1 | |
| 9F2978 | NUT-WELD (3/8-16-THD) | 1 | |
| 3161876 | 6 STRIP-RUBBER | 1 | |
| 3161877 | 7 STRIP-RUBBER | 1 | |
| 3164431 | 8 BRACKET AS | 2 | |
| 1653928 | 9 BOLT (3/8-16-THD) | 2 | |
| 1757141 | 10 NUT-HEX FLANGE (M10X1.5-THD) | 6 | |
| 5M3062 | 11 BOLT (3/8-16X0.75-IN) | 1 | |
| 5S7379 | 12 BOLT (3/8-16X0.875-IN) | 2 | |
| 8T4121 | 13 WASHER-HARD (11X21X2.5-MM THK) | 17 | |
| 8T4136 | 14 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4137 | 15 BOLT (M10X1.5X20-MM) | 11 | |
| 8T4896 | 16 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 9M2307 | 17 WASHER (5.2X19X2-MM THK) | 8 | |
| 9X6458 | 18 WASHER-HARD (10.2X22.5X3-MM THK) | 2 |
