System And Components
Assembly
100%

245-6063 DASH GPS/N DBB1-UP

Group No: 245-6063 · Commonality
Part NumberPart NameQty
3E69241 SCREW-TRUSS HEAD (M6X1X50-MM)2
8Y57462 ASHTRAY1
8Y63883 LOUVER AS-VENT5
8Y63334 GASKET (ASHTRAY)2
16223235 COVER (INSTRUMENT)1
16223266 COVER (LOWER, RH)1
16223277 COVER (STEERING COLUMN)1
16223308 COVER1
18425359 DOOR AS1
3H0240WASHER (5X9.7X0.8-MM THK)11
5P5930SEAL (0.8-M)
7M1530RIVET-POP11
1588581HINGE AS1
1882702LATCH AS1
228077310 PLENUM (LOWER)1
245606111 PLENUM (UPPER)1
248125612 PLENUM (INSTRUMENT)1
365653113 COVER AS1
101286714 WASHER-HARD (7.2X25X2-MM THK)2
104209115 SCREW-FLAT HEAD (6-20X0.5-IN)10
8Y633416 GASKET (ASHTRAY)2
8T420518 WASHER-HARD (7.2X14.5X2-MM THK)4
9X203819 WASHER (7X19X2-MM THK)38
9X204220 SCREW-TRUSS HEAD (M6X1X12-MM)2
9X204321 SCREW-TRUSS HEAD (M6X1X14-MM)31
9X204522 SCREW-TRUSS HEAD (M6X1X20-MM)7
9X204623 SCREW-TRUSS HEAD (M6X1X35-MM)4
5P592124 SEAL (0.1-M)
5P592124A SEAL (0.06-M)
5P592124B SEAL (0.04-M)
129317825 LOCKNUT (M6X1-THD)4
