System And Components
154-2482 DOOR GP-CABS/N DBB1-UP
Group No: 154-2482 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2A6392 | 1 GLASS | 1 | |
| 2A6397 | 2 STRAP | 1 | |
| 5T5270 | 3 ANGLE | 1 | |
| 6G9485 | 4 LEVER | 1 | |
| 6V2375 | 5 HANDLE AS-INSIDE | 1 | |
| 6V7636 | 6 PIN AS-SPRING | 4 | |
| 8X9739 | 7 WINDOW GP | 1 | |
| 1068832 | 8 STRIKER AS-BODY | 1 | |
| 1564619 | 9 DOOR AS | 1 | |
| 1668062 | 10 COVER | 1 | |
| 1668063 | 11 COVER | 1 | |
| 1707708 | 12 LATCH AS | 1 | |
| 1707709 | 13 HANDLE AS-DOOR (OUTSIDE) | 1 | |
| 8Y4501 | SPRING-HANDLE | 1 | |
| 8Y6338 | BRACKET-MOUNTING | 2 | |
| 1757785 | 14 LINK AS | 1 | |
| 1915077 | 15 STRAP | 2 | |
| 1915096 | 16 LUG | 1 | |
| 1964785 | 17 HANDHOLD | 1 | |
| 1973133 | 18 LINK AS | 1 | |
| 6V8185 | NUT (1/4-20-THD) | 1 | |
| 1085471 | CLEVIS | 1 | |
| 0310215 | 19 BOLT-LOCKING (1/4-20X0.625-IN) | 2 | |
| 0310216 | 20 BOLT (1/4-20X0.75-IN) | 4 | |
| 1249022 | 21 SCREW-BUTTON HEAD (3/8-16X2.25-IN) | 1 | |
| 1H3337 | 22 BOLT (1/4-20X0.875-IN) | 5 | |
| 4L6454 | 23 BOLT (3/8-16X1-IN) | 8 | |
| 5P4115 | 24 WASHER-HARD (7.2X19X2-MM THK) | 6 | |
| 6V7357 | 25 BOLT (M6X1X25-MM) | 4 | |
| 6V8801 | 26 NUT (3/8-16-THD) | 1 | |
| 8H3128 | 27 BOLT-SOCKET HEAD (1/4-20X0.625-IN) | 2 | |
| 8T4205 | 28 WASHER-HARD (7.2X14.5X2-MM THK) | 10 | |
| 8T4896 | 29 WASHER-HARD (10.2X18.5X2.5-MM THK) | 8 | |
| 9X2044 | 30 SCREW-TRUSS HEAD (M6X1X16-MM) | 4 | |
| 5P8309 | 31 SEAL (4.7-M) | ||
| 5P6605 | 32 SEAL (5.3-M) | ||
| 8Y6378 | 33 SEAL-HANDLE | 1 |
