System And Components
266-5938 ROPS GP -ENCLOSEDS/N DBB1-579
Group No: 266-5938 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3T3635 | 1 HANDHOLD | 2 | |
| 6G2128 | 2 CLIP | 8 | |
| 6V8928 | 3 HOOK-COAT | 1 | |
| 7I5891 | 4 FOOTREST AS | 1 | |
| 7I5893 | ROD | 2 | |
| 7L6362 | BOSS | 2 | |
| 7V6063 | 5 BOLT AS | 6 | |
| 8Y6379 | 6 KIT-HAMMER (CAB WINDOW) | 1 | |
| 1005612 | 7 FILM-INSTRUCTION (ALTERNATE EXIT, REMOVE WINDOW) | 1 | |
| 1784455 | 8 FLOOR MAT (ROPS) | 1 | |
| 1859464 | 9 LATCH AS (COMPARTMENT) | 2 | |
| 1947580 | 10 HANDHOLD | 1 | |
| 2012648 | 11 COVER | 1 | |
| 2019109 | 12 DOOR GP-ACCESS (BREAKERS, 24-VOLT OUTLET) | 1 | |
| 2334871 | CAM | 1 | |
| 2260295 | LOCK AS | 1 | |
| 2036066 | LATCH AS | 1 | |
| 2196036 | DOOR AS | 1 | |
| 1V8284 | HINGE | 1 | |
| 2906053 | 13 STEP AS | 1 | |
| 7D0734 | WASHER (0.656X2.38X0.25-IN THK) | 2 | |
| 1411497 | NUT (1/2-13-THD) | 2 | |
| 2903372 | CUSHION AS | 2 | |
| 2596310 | 14 INSULATION | 1 | |
| 2530034 | 15 DOOR GP-ACCESS (FUSE PANEL) | 1 | |
| 2336583 | 16 PLATE AS | 1 | |
| 2645903 | 17 ROLLOVER AS | 1 | |
| 3R0451 | BOSS (3/8-16-THD) | 2 | |
| 8X4245 | BOSS (M6X1X18-MM) | 4 | |
| 2994312 | PLATE AS | 2 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 2649658 | 18 COVER GP-ACCESS (AIR CONDITIONER) | 1 | |
| 5P2228 | 19 BOLT (1/2-13X1-IN) | 6 | |
| 7X0325 | 20 BOLT (1/2-13X2.5-IN) | 2 | |
| 8T4121 | 21 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4137 | 22 BOLT (M10X1.5X20-MM) | 4 | |
| 8T4223 | 23 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 9N1995 | 24 RIVET-POP | 4 | |
| 9X2042 | 25 SCREW-TRUSS HEAD (M6X1X12-MM) | 2 | |
| 9X2045 | 26 SCREW-TRUSS HEAD (M6X1X20-MM) | 1 | |
| 0924924 | 27 PLUG-BUTTON | 1 | |
| 7X2619 | 28 BOLT (M6X1X10-MM) | 4 | |
| 5C9553 | 29 BOLT (M6X1X16-MM) | 3 |
