System And Components
443-8245 SEAT GP-SUSPENSION -CLOTHS/N DBB1-UP
Group No: 443-8245 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1431288 | 1 LOCKNUT-FLANGE (3/8-16-THD) | 8 | |
| 1644883 | 2 KNOB-LUMBAR | 1 | |
| 1771863 | 3 BOLT-PIVOT (3/8-16X2.89-IN) | 2 | |
| 2182529 | 4 PLUG | 3 | |
| 2620767 | 5 BRACKET AS (LH) | 1 | |
| 2778103 | 6 PLUG | 3 | |
| 4438291 | 7 ARMREST GP (LH) | 1 | |
| 4438292 | 8 ARMREST GP (RH) | 1 | |
| 2926402 | 9 PAN GP-BACKREST (LUMBAR) | 1 | |
| 3145162 | 10 BRACKET AS (RH) | 1 | |
| 4425287 | 11 KIT-SHAFT (RECLINER) | 1 | |
| 3553016 | 12 PLATE AS | 1 | |
| 3699004 | 13 CABLE AS | 1 | |
| 3890879 | 14 PAN-SEAT BACK | 1 | |
| 1711230 | 15 SCREW-BUTTON HEAD (3/8-16X1-IN) | 6 | |
| 8T7566 | 16 PIN-SPRING | 1 | |
| 9F5975 | 17 BOLT (5/16-18X0.75-IN) | 1 | |
| 4361687 | 18 KIT-LATCH (SEAT ADJUSTMENT) | 1 | |
| 4361688 | 19 KIT-SEAT (TILT) | 1 | |
| 4438573 | 20 KIT-HANDLE (SEAT ADJUSTMENT) | 1 | |
| 4460638 | 21 KIT-SEAT CUSHION (CLOTH) | 1 |
