System And Components
372-7949 SUSPENSION GP-SEAT -AIRS/N DBB379-UP
Group No: 372-7949 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 2 | |
| 7G1060 | 2 STRAP AS-GROUND | 1 | |
| 8L8413 | 3 STRAP-CABLE (WHITE) | 2 | |
| 1028802 | 4 KIT-RECEPTACLE (2-PIN) | 1 | |
| 1641234 | 5 PLATE | 1 | |
| 1755052 | 6 SPRING AS-AIR | 1 | |
| 1755054 | 7 CAP | 1 | |
| 1755059 | 8 KIT-ROLLER | 1 | |
| 1862094 | 9 RETAINER | 1 | |
| 1862098 | 10 KIT-FASTENER | 1 | |
| 1862099 | 11 KIT-TETHER | 1 | |
| 2746719 | 12 SENSOR GP-PRESSURE | 1 | |
| 3667658 | 13 HARNESS AS-WIRING (SEAT, SENSOR) | 1 | |
| 3829946 | 14 CONTROLLER AS (RIDE CONTROL) | 1 | |
| 3836205 | 15 COVER | 1 | |
| 3836206 | 16 BRACKET | 1 | |
| 3836207 | 17 BOOT | 1 | |
| 3848595 | 18 KIT-VALVE | 1 | |
| 3855572 | 19 BLOCK | 2 | |
| 3893198 | 20 KIT-SEAT SUSPENSION | 1 | |
| 3893199 | 21 KIT-SENSOR | 1 | |
| 3893200 | 22 KIT-RECEPTACLE CONNECTOR | 1 | |
| 3893201 | 23 KIT-SEAT AIR COMPRESSOR | 1 | |
| 3910258 | 24 FILM-INSTRUCTION (SEAT ADJUSTMENT) | 1 | |
| 3926383 | 25 KIT-SHOCK ABSORBER | 1 | |
| 3961721 | 26 HARNESS AS-WIRING (SEAT, COMPRESSOR) | 1 | |
| 0314155 | 27 LOCKNUT (5/16-18-THD) | 3 | |
| 0338755 | 28 SCREW (1/4-20X1-IN) | 3 | |
| 0L1351 | 29 BOLT (3/8-16X0.875-IN) | 2 | |
| 0S0509 | 30 BOLT (3/8-16X0.75-IN) | 1 | |
| 0S1617 | 31 BOLT (5/16-18X0.75-IN) | 2 | |
| 0S1620 | 32 BOLT (1/2-13X0.75-IN) | 1 | |
| 1138665 | 33 BUMPER-RUBBER | 3 | |
| 1H3338 | 34 LOCKWASHER | 2 | |
| 2D6235 | 35 LOCKNUT (1/4-20-THD) | 4 | |
| 5P0537 | 36 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 5P4423 | 37 ELBOW | 1 | |
| 5P8245 | 38 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 7X2501 | 39 BOLT (1/4-20X1.25-IN) | 4 | |
| 8T4205 | 40 WASHER-HARD (7.2X14.5X2-MM THK) | 3 | |
| 8T9380 | 41 BOLT (7/16-14X1-IN) | 4 | |
| 9X6458 | 42 WASHER-HARD (10.2X22.5X3-MM THK) | 2 | |
| 5P6010 | 43 TUBE |
