System And Components
417-6077 SUSPENSION GP-SEAT -AIRS/N DBB379-UP
Group No: 417-6077 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 2 | |
| 8L8413 | 3 STRAP-CABLE (WHITE) | 2 | |
| 1028802 | 4 KIT-RECEPTACLE (2-PIN) | 1 | |
| 1641234 | 5 PLATE | 1 | |
| 1755052 | 6 SPRING AS-AIR | 1 | |
| 1755054 | 7 CAP | 1 | |
| 1755059 | 8 KIT-ROLLER | 1 | |
| 1862094 | 9 RETAINER | 1 | |
| 1862098 | 10 KIT-FASTENER | 1 | |
| 1862099 | 11 KIT-TETHER | 1 | |
| 2464311 | 12 GUARD (SWITCH) | 1 | |
| 2746719 | 13 SENSOR GP-PRESSURE | 1 | |
| 3667658 | 14 HARNESS AS-WIRING (SEAT, SENSOR) | 1 | |
| 3836206 | 15 BRACKET | 1 | |
| 1862092 | 16 BOOT | 1 | |
| 3848595 | 17 KIT-VALVE | 1 | |
| 1862093 | 18 BLOCK | 2 | |
| 3856123 | 19 SWITCH AS-ROCKER (DAMPENING) | 1 | |
| 3883554 | 20 CONTROL GP-ELECTRONIC (RIDE CONTROL) | 1 | |
| 3893198 | 21 KIT-SEAT SUSPENSION | 1 | |
| 3893200 | 22 KIT-RECEPTACLE CONNECTOR | 1 | |
| 3893201 | 23 KIT-SEAT AIR COMPRESSOR | 1 | |
| 3910258 | 24 FILM-INSTRUCTION (SEAT ADJUSTMENT) | 1 | |
| 3926383 | 25 KIT-SHOCK ABSORBER | 1 | |
| 4184764 | 26 BRACKET | 1 | |
| 4184765 | 27 HARNESS AS-WIRING (SEAT, COMPRESSOR) | 1 | |
| 0314155 | 28 LOCKNUT (5/16-18-THD) | 3 | |
| 0338755 | 29 SCREW (1/4-20X1-IN) | 3 | |
| 0S0509 | 31 BOLT (3/8-16X0.75-IN) | 1 | |
| 0S1617 | 32 BOLT (5/16-18X0.75-IN) | 2 | |
| 0S1620 | 33 BOLT (1/2-13X0.75-IN) | 1 | |
| 1138665 | 34 BUMPER-RUBBER | 3 | |
| 1D4669 | 35 BOLT-CARRIAGE (1/4-20X1-IN) | 2 | |
| 2D6235 | 36 LOCKNUT (1/4-20-THD) | 4 | |
| 3V2431 | 37 WASHER (10.2X16X2-MM THK) | 2 | |
| 4K9429 | 38 RIVET-POP | 2 | |
| 5P0537 | 39 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 5P4423 | 40 ELBOW | 1 | |
| 5P8245 | 41 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 7X2501 | 42 BOLT (1/4-20X1.25-IN) | 2 | |
| 8T4205 | 43 WASHER-HARD (7.2X14.5X2-MM THK) | 3 | |
| 8T9380 | 44 BOLT (7/16-14X1-IN) | 4 | |
| 5P6010 | 46 TUBE | 1 |
