System And Components
451-5454 SUSPENSION GP-SEAT -AIRS/N DBB1-UP
Group No: 451-5454 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1641234 | 1 PLATE | 1 | |
| 1755052 | 2 SPRING AS-AIR | 1 | |
| 1755054 | 3 CAP | 1 | |
| 1755059 | 4 KIT-ROLLER (SUSPENSION SEAT) | 1 | |
| 1862092 | 5 BOOT | 1 | |
| 1862093 | 6 BLOCK | 2 | |
| 1862094 | 7 RETAINER | 1 | |
| 1862098 | 8 KIT-FASTENER (SUSPENSION SEAT) | 1 | |
| 1862099 | 9 KIT-TETHER (SUSPENSION SEAT) | 1 | |
| 8T9380 | 10 BOLT (7/16-14X1-IN) | 4 | |
| 2464311 | 11 GUARD (SWITCH) | 1 | |
| 2746719 | 12 SENSOR GP-PRESSURE (SUSPENSION SEAT) | 1 | |
| 3848595 | 13 KIT-VALVE (SUSPENSION SEAT) | 1 | |
| 3883554 | 14 CONTROL GP-ELECTRONIC (RIDE CONTROL) | 1 | |
| 3893200 | 15 KIT-RECEPTACLE CONNECTOR (SUSPENSION SEAT) | 1 | |
| 3893201 | 16 KIT-SEAT AIR COMPRESSOR | 1 | |
| 3910258 | 17 FILM-INSTRUCTION (SEAT ADJUSTMENT) | 1 | |
| 3914971 | 18 KIT-SEAT SUSPENSION | 1 | |
| 3926383 | 19 KIT-SHOCK ABSORBER (SUSPENSION SEAT) | 1 | |
| 4184764 | 20 BRACKET | 1 | |
| 4258951 | 21 SWITCH AS-ROCKER (DAMPENING) | 1 | |
| 4404581 | 22 SOFTWARE GP-MACHINE | 1 | |
| 4759153 | 23 WIRING GP-SEAT (SEAT SUSPENSION) | 1 | |
| 0314155 | 24 LOCKNUT (5/16-18-THD) | 3 | |
| 9W1464 | 25 SCREW (1/4-20X1-IN) | 3 | |
| 0S0509 | 26 BOLT (3/8-16X0.75-IN) | 1 | |
| 0S1617 | 27 BOLT (5/16-18X0.75-IN) | 2 | |
| 0S1620 | 28 BOLT (1/2-13X0.75-IN) | 1 | |
| 1138665 | 29 BUMPER-RUBBER | 3 | |
| 1D4669 | 30 BOLT-CARRIAGE (1/4-20X1-IN) | 2 | |
| 2D6235 | 31 LOCKNUT (1/4-20-THD) | 4 | |
| 4K9429 | 32 RIVET-POP | 2 | |
| 5P0537 | 33 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 5P8245 | 34 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 7X2501 | 35 BOLT (1/4-20X1.25-IN) | 2 | |
| 8T4205 | 36 WASHER-HARD (7.2X14.5X2-MM THK) | 3 |
