System And Components
451-5455 SUSPENSION GP-SEAT -AIRS/N DBB379-UP
Group No: 451-5455 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1641234 | 1 PLATE | 1 | |
| 1755052 | 2 SPRING AS-AIR | 1 | |
| 1755054 | 3 CAP | 1 | |
| 1755059 | 4 KIT-ROLLER | 1 | |
| 1862092 | 5 BOOT | 1 | |
| 1862093 | 6 BLOCK | 2 | |
| 1862094 | 7 RETAINER | 1 | |
| 1862098 | 8 KIT-FASTENER | 1 | |
| 1862099 | 9 KIT-TETHER | 1 | |
| 2464311 | 10 GUARD (SWITCH) | 1 | |
| 2746719 | 11 SENSOR GP-PRESSURE (SUSPENSION SEAT) | 1 | |
| 3848595 | 12 KIT-VALVE | 1 | |
| 3883554 | 13 CONTROL GP-ELECTRONIC (RIDE CONTROL) | 1 | |
| 3893198 | 14 KIT-SEAT SUSPENSION | 1 | |
| 3893200 | 15 KIT-RECEPTACLE CONNECTOR | 1 | |
| 3893201 | 16 KIT-SEAT AIR COMPRESSOR | 1 | |
| 3910258 | 17 FILM-INSTRUCTION (SEAT ADJUSTMENT) | 1 | |
| 5038825 | 18 KIT-SHOCK ABSORBER | 1 | |
| 4184764 | 19 BRACKET | 1 | |
| 4258951 | 20 SWITCH AS-ROCKER (DAMPENING) | 1 | |
| 4404581 | 21 SOFTWARE GP-MACHINE | 1 | |
| 0314155 | 23 LOCKNUT (5/16-18-THD) | 3 | |
| 9W1464 | 24 SCREW (1/4-20X1-IN) | 3 | |
| 0S0509 | 25 BOLT (3/8-16X0.75-IN) | 1 | |
| 0S1617 | 26 BOLT (5/16-18X0.75-IN) | 2 | |
| 0S1620 | 27 BOLT (1/2-13X0.75-IN) | 1 | |
| 1138665 | 28 BUMPER-RUBBER | 3 | |
| 1D4669 | 29 BOLT-CARRIAGE (1/4-20X1-IN) | 2 | |
| 2D6235 | 30 LOCKNUT (1/4-20-THD) | 4 | |
| 4K9429 | 31 RIVET-POP | 2 | |
| 5P0537 | 32 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 5P8245 | 33 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 7X2501 | 34 BOLT (1/4-20X1.25-IN) | 2 | |
| 8T4205 | 35 WASHER-HARD (7.2X14.5X2-MM THK) | 3 | |
| 8T9380 | 36 BOLT (7/16-14X1-IN) | 4 |
