System And Components
215-8333 WIPER & WASHER GP-WINDOW -FRONT, REARS/N DBB1-UP
Group No: 215-8333 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 9 | |
| 5C8811 | 2 BLADE AS-WIPER (500-MM) | 2 | |
| 8T5400 | 3 CONNECTOR | 2 | |
| 8X9200 | 4 PLATE | 2 | |
| 1645663 | 5 COVER | 2 | |
| 2015036 | 6 ARM AS | 2 | |
| 1945171 | HOSE (33-CM) | ||
| 3059191 | NOZZLE AS-WASHER | 1 | |
| 2016903 | 7 MOTOR GP-WINDOW WIPER | 2 | |
| 1350611 | MOTOR GP-WINDOW WIPER (24-VOLT, 2-SPEED) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | ||
| 8T8737 | PLUG-SEAL | 1 | |
| 1028805 | KIT-RECEPTACLE (6-PIN) | 1 | |
| 1943710 | CAP-WIPER | 1 | |
| 3623507 | KIT-REPAIR (WINDOW WIPER ARM) | 1 | |
| 2027868 | 8 BRACKET AS | 2 | |
| 2G8096 | 9 MOUNTING | 1 | |
| 8T4121 | 10 WASHER-HARD (11X21X2.5-MM THK) | 8 | |
| 8T4133 | 11 NUT (M10X1.5-THD) | 4 | |
| 8T4137 | 12 BOLT (M10X1.5X20-MM) | 4 | |
| 9X2044 | 13 SCREW-TRUSS HEAD (M6X1X16-MM) | 8 | |
| 9X2480 | 14 BOLT (M6X1X45-MM) | 2 | |
| 9X8256 | 15 WASHER (6.6X12X2-MM THK) | 2 | |
| 1440195 | 16 HOSE (305-CM) | ||
| 1440195 | 16A HOSE (235-CM) | ||
| 7K1181 | 17 STRAP-CABLE | 1 |
