System And Components
325-3266 ACCESSORY GP-ENGINE -ALTERNATOR, AIR CONDITIONER COMPRESSORS/N DBC508-525
Group No: 325-3266
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2280503 | 1 COMPRESSOR GP-REFRIGERANT (AIR CONDITIONER) | 1 | |
| 2302185 | 2 BELT TENSIONER GP | 1 | |
| 2848443 | 3 BRACKET AS (FRONT) | 1 | |
| 1593042 | NUT-WELD (M10X1.5-THD) | 3 | |
| 3229751 | 4 GUARD AS | 1 | |
| 3263501 | 5 BRACKET AS (UPPER) | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 3418144 | 6 ALTERNATOR GP-CHARGING | 1 | |
| 2923198 | 7 WASHER-HARD (13.5X25.5X9-MM THK) | 2 | |
| 5P2566 | 8 BOLT (1/2-13X1.5-IN) | 2 | |
| 7X7729 | 9 WASHER (11X25X3-MM THK) | 1 | |
| 8T4186 | 10 BOLT (M10X1.5X40-MM) | 1 | |
| 8T4222 | 11 WASHER-PLATED (11X32X2.5-MM THK) | 3 | |
| 9X2125 | 12 BOLT-LOCKING (M10X1.5X25-MM) | 3 |
