System And Components
351-8733 OPTION AR-GUARDS/N DBZ1-UP
Group No: 351-8733
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1165763 | 1 CLIP-SPRING | 4 | |
| 3226554 | 2 BRACKET | 1 | |
| 3226568 | 3 BRACKET AS | 1 | |
| 3264148 | 4 GUARD AS | 1 | |
| 6H7062 | SPACER (13.5X25X19-MM THK) | 1 | |
| 3264174 | 5 GUARD AS | 1 | |
| 3289952 | 6 PLATE-PIN | 1 | |
| 0910081 | 7 SPACER (10.5X20X10-MM THK) | 1 | |
| 2923198 | 8 WASHER-HARD (13.5X25.5X9-MM THK) | 1 | |
| 2M0849 | 9 WASHER-HARD (13.5X25.5X5-MM THK) | 1 | |
| 5P4116 | 10 WASHER-HARD (8.8X20.5X2-MM THK) | 4 | |
| 7X7729 | 11 WASHER (11X25X3-MM THK) | 4 | |
| 8T4133 | 12 NUT (M10X1.5-THD) | 2 | |
| 8T4186 | 13 BOLT (M10X1.5X40-MM) | 2 | |
| 8T4196 | 14 BOLT (M10X1.5X35-MM) | 1 | |
| 8T4908 | 15 BOLT (M8X1.25X25-MM) | 4 | |
| 8T8919 | 16 BOLT (1/2-13X1.75-IN) | 1 | |
| 8T9389 | 17 BOLT (1/2-13X2.75-IN) | 1 |
