System And Components
263-3291 ADAPTER GP-FAST FILL FUELS/N DBZ923-932
Group No: 263-3291
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 2 | |
| 9D0630 | 2 CAP-DUST | 1 | |
| 1242463 | 3 ADAPTER-FAST FILL FUEL | 1 | |
| 1635455 | 4 VALVE AS-SHUTOFF (FAST FILL FUEL) | 1 | |
| 1885095 | 5 VENT AS | 1 | |
| 2623086 | 6 HOSE AS | 1 | |
| 2750137 | 7 GUARD AS | 1 | |
| 3142791 | 8 PLATE AS | 1 | |
| 3177888 | 9 TUBE AS | 1 | |
| 1686890 | 10 CLIP (SLOT) | 1 | |
| 1686891 | 11 CLIP (TAB) | 1 | |
| 1984778 | 12 WASHER-HARD (13.5X30X12-MM THK) | 4 | |
| 1J9671 | 13 SEAL-O-RING | 2 | |
| 1P3709 | 14 SEAL-RECTANGULAR | 1 | |
| 5H6734 | 15 SEAL-O-RING | 1 | |
| 5M3062 | 16 BOLT (3/8-16X0.75-IN) | 3 | |
| 5P2369 | 17 CLIP (LOOP) | 1 | |
| 5P2566 | 18 BOLT (1/2-13X1.5-IN) | 5 | |
| 5P2618 | 19 CONNECTOR | 2 | |
| 6V1574 | 20 GROMMET | 1 | |
| 7L6326 | 21 CLIP | 3 | |
| 7X0332 | 22 BOLT (1/2-13X4.5-IN) | 4 | |
| 8H7521 | 23 SEAL-O-RING | 1 | |
| 8T4121 | 24 WASHER-HARD (11X21X2.5-MM THK) | 6 | |
| 8T4195 | 25 BOLT (M10X1.5X30-MM) | 6 | |
| 8T4223 | 26 WASHER-HARD (13.5X25.5X3-MM THK) | 5 | |
| 8T4896 | 27 WASHER-HARD (10.2X18.5X2.5-MM THK) | 9 | |
| 8T4983 | 28 CLAMP-HOSE | 1 | |
| 9B7237 | 29 BOLT (3/8-16X1.25-IN) | 6 | |
| 5P1253 | 30 HOSE (323-CM) |
