System And Components
228-4477 LINES GP-FUEL -FILTERS/N THX1-649
Group No: 228-4477
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE (PLASTIC) | 3 | |
| 0839527 | 2 SPACER (13X20X1.5-MM THK) | 1 | |
| 1266872 | 3 TEE | 1 | |
| 1833398 | 4 CONNECTOR AS (FACE SEAL) | 1 | |
| 6V5049 | SEAL-O-RING | 1 | |
| 8L2779 | SEAL-O-RING | 1 | |
| 1833403 | 5 ELBOW AS (90-DEG) | 1 | |
| 6V5049 | SEAL-O-RING | 1 | |
| 8L2779 | SEAL-O-RING | 1 | |
| 1833405 | 6 TEE AS | 1 | |
| 6V5049 | SEAL-O-RING | 1 | |
| 8L2779 | SEAL-O-RING | 1 | |
| 1833406 | 7 PLUG AS (HIGH TEMPERATURE) | 3 | |
| 6V5049 | SEAL-O-RING | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 1906785 | 8 BRACKET AS | 1 | |
| 1907383 | 9 TUBE AS | 1 | |
| 1998037 | 10 PLATE AS | 1 | |
| 2051306 | 11 REGULATOR GP-FUEL PRESSURE | 1 | |
| 2069392 | 12 HOSE AS | 1 | |
| 2130064 | 13 BASE AS (FUEL) | 1 | |
| 9S4167 | STUD-HOLLOW (1-14X1.47-IN) | 1 | |
| 2331752 | 14 TUBE AS | 1 | |
| 2392396 | 15 SENSOR GP-PRESSURE (FUEL) | 1 | |
| 2580883 | 16 SWITCH GP-PRESSURE (BYPASS, FUEL) | 1 | |
| 2604861 | 17 HARNESS AS-WIRING (FUEL PRESSURE) | 1 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 1028806 | KIT-RECEPTACLE (8-PIN) | 1 | |
| 8T8737 | PLUG-SEAL | 3 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 1 | |
| 2609235 | 18 VALVE AS-BALL (OUTLET) | 2 | |
| 1305300 | 19 CLIP | 1 | |
| 1488336 | 20 CONNECTOR AS (STORAGE) | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1488363 | 21 ELBOW AS | 1 | |
| 6V9876 | ELBOW | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1R0762 | 22 FILTER-FUEL (ADVANCED EFFICIENCY)(SECONDARY) | 1 | |
| 2R6806 | 23 CONNECTOR | 1 | |
| 3E4353 | 24 WASHER-HARD (11X25X3-MM THK) | 3 | |
| 4P7581 | 25 CLIP (LADDER) | 1 | |
| 5P9297 | 26 CLIP (LOOP) | 1 | |
| 6V3265 | 27 CLIP | 1 | |
| 6V3822 | 28 BOLT (M10X1.5X35-MM) | 1 | |
| 6V4248 | 29 BOLT (M10X1.5X25-MM) | 6 | |
| 6V5049 | 30 SEAL-O-RING | 4 | |
| 6V5839 | 31 WASHER (11X21X2.5-MM THK) | 5 | |
| 6V5844 | 32 BOLT (M16X2X35-MM) | 3 | |
| 6V6317 | 33 BOLT (M10X1.5X20-MM) | 1 | |
| 8L2779 | 34 SEAL-O-RING | 1 | |
| 8T0151 | 35 ADAPTER (OIL TEMPERATURE SENSOR) | 1 | |
| 9X0261 | 36 ADAPTER | 1 | |
| 9X8268 | 37 WASHER (17.5X30X3.5-MM THK) | 3 |
