System And Components
228-4477 LINES GP-FUEL -FILTERS/N THX1-UP
Group No: 228-4477
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE (PLASTIC) | 3 | |
| 0839527 | 2 SPACER (13X20X1.5-MM THK) | 2 | |
| 1266872 | 3 TEE (ORFS) | 2 | |
| 1833398 | 4 CONNECTOR AS (FACE SEAL) | 1 | |
| 6V5049 | SEAL-O-RING | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 8L2779 | SEAL-O-RING | 1 | |
| 1833403 | 5 ELBOW AS (90-DEG) | 1 | |
| 6V5049 | SEAL-O-RING | 1 | |
| 6V8724 | ELBOW | 1 | |
| 8L2779 | SEAL-O-RING | 1 | |
| 1833406 | 6 PLUG AS (HIGH TEMPERATURE) | 3 | |
| 6V5049 | SEAL-O-RING | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 3071902 | 7 BRACKET AS | 1 | |
| 1907383 | 8 TUBE AS | 1 | |
| 1998037 | 9 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 2298871 | 10 REGULATOR AS (FUEL PRESSURE) | 1 | |
| 2069392 | 11 HOSE AS | 1 | |
| 2130064 | 12 BASE AS (FUEL) | 1 | |
| 9S4167 | STUD-HOLLOW (1-14X1.47-IN) | 1 | |
| 2331752 | 13 TUBE AS | 1 | |
| 2392396 | 14 SENSOR GP-PRESSURE (FUEL) | 1 | |
| 2580883 | 15 SWITCH GP-PRESSURE (FUEL) | 1 | |
| 2604861 | 16 HARNESS AS-WIRING (FUEL PRESSURE) | 1 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 1028806 | KIT-RECEPTACLE (8-PIN) | 1 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 1 | |
| 2609235 | 17 VALVE AS-BALL (FUEL DRAIN) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2609233 | VALVE-BALL | 1 | |
| 2609236 | 18 VALVE AS-BALL (OUTLET) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2609234 | VALVE-SHUTOFF | 1 | |
| 2831226 | 19 BRACKET AS | 1 | |
| 1305300 | 20 CLIP | 1 | |
| 1488336 | 21 CONNECTOR AS (STORAGE) | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1488363 | 22 ELBOW AS | 1 | |
| 6V9876 | ELBOW | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1R0762 | 23 FILTER-FUEL (ADVANCED EFFICIENCY)(SECONDARY) | 1 | |
| 1861667 | 24 CONNECTOR AS | 1 | |
| 2R6806 | CONNECTOR | 1 | |
| 6V5049 | SEAL-O-RING | 1 | |
| 3E4353 | 25 WASHER-HARD (11X25X3-MM THK) | 4 | |
| 4P7581 | 26 CLIP (LADDER) | 1 | |
| 5P9297 | 27 CLIP (LOOP) | 2 | |
| 6V3265 | 28 CLIP | 1 | |
| 6V3822 | 29 BOLT (M10X1.5X35-MM) | 1 | |
| 6V4248 | 30 BOLT (M10X1.5X25-MM) | 7 | |
| 6V5049 | 31 SEAL-O-RING | 4 | |
| 6V5839 | 32 WASHER (11X21X2.5-MM THK) | 6 | |
| 6V5844 | 33 BOLT (M16X2X35-MM) | 3 | |
| 6V6317 | 34 BOLT (M10X1.5X20-MM) | 1 | |
| 8L2779 | 35 SEAL-O-RING | 2 | |
| 8T0151 | 36 ADAPTER | 1 | |
| 9X0261 | 37 ADAPTER | 1 | |
| 9X8268 | 38 WASHER (17.5X30X3.5-MM THK) | 3 |
