System And Components
228-6779 LINES GP-FUELS/N DBZ938-UP
Group No: 228-6779
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5P4961 | 1 CLAMP-HOSE | 3 | |
| 8T6724 | 2 VALVE-BALL | 1 | |
| 3125760 | 3 HOSE AS | 1 | |
| 3497284 | 4 HOSE AS | 1 | |
| 1498142 | 5 CONNECTOR | 1 | |
| 1590225 | 6 HOSE AS | 1 | |
| 1997686 | 7 HOSE AS | 1 | |
| 2476483 | 8 HOSE AS | 1 | |
| 2542438 | 9 PLATE | 1 | |
| 0338248 | 10 CLIP (LOOP) | 1 | |
| 1004336 | 11 CLIP (LOOP) | 2 | |
| 1488340 | 12 CONNECTOR AS | 2 | |
| 6V8639 | CONNECTOR | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1488366 | 13 ELBOW AS | 1 | |
| 6V8987 | ELBOW | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 1488380 | 14 ELBOW AS | 1 | |
| 6V8988 | ELBOW | 1 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 1488439 | 15 TEE AS | 1 | |
| 6V8774 | TEE | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 1488444 | 16 TEE AS-SWIVEL | 1 | |
| 6V9837 | TEE-SWIVEL | 1 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 1504037 | 17 TEE AS | 1 | |
| 6V9844 | TEE-SWIVEL | 1 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 1716728 | 18 ELBOW AS | 1 | |
| 8T0249 | ELBOW (SWIVEL) | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 1P4278 | 19 CLAMP-HOSE | 1 | |
| 1S0994 | 20 CLIP (LOOP) | 14 | |
| 1S6420 | 21 CLIP | 2 | |
| 3K0360 | 22 SEAL-O-RING | 3 | |
| 4L6454 | 23 BOLT (3/8-16X1-IN) | 1 | |
| 5K1094 | 24 LOCKWASHER | 1 | |
| 5M3062 | 25 BOLT (3/8-16X0.75-IN) | 11 | |
| 5P4295 | 26 CLIP | 2 | |
| 2462641 | 27 PADLOCK GP | 1 | |
| 5P8500 | KEY | 1 | |
| 5S7379 | 28 BOLT (3/8-16X0.875-IN) | 11 | |
| 9X8257 | 29 WASHER (17.5X30X3.5-MM THK) | 1 | |
| 6V1889 | 30 CLIP (LOOP) | 2 | |
| 6V8367 | 31 LOCKWASHER | 1 | |
| 6V8398 | 32 SEAL-O-RING | 1 | |
| 6V8801 | 33 NUT (3/8-16-THD) | 1 | |
| 6V9168 | 34 NUT (11/16-16-THD) | 1 | |
| 6V9169 | 35 NUT (13/16-16-THD) | 1 | |
| 7D7233 | 36 CLIP (LOOP) | 2 | |
| 8M2773 | 37 CLIP (LOOP) | 12 | |
| 8T4123 | 38 WASHER (22X35X3.5-MM THK) | 1 | |
| 8T4179 | 39 BOLT (M12X1.75X20-MM) | 2 | |
| 8T4223 | 40 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 8T4896 | 41 WASHER-HARD (10.2X18.5X2.5-MM THK) | 13 | |
| 8T5464 | 42 VALVE-BALL | 1 | |
| 8C6959 | 43 HOSE (139-CM) | ||
| 5P1442 | 44 HOSE (96-CM) | ||
| 5P1442 | 44A HOSE (95-CM) | ||
| 5P1442 | 44B HOSE (36-CM) | ||
| 5P1075 | 45 WASHER-HARD (10.2X22.5X3-MM THK) | 12 | |
| 9B7237 | 46 BOLT (3/8-16X1.25-IN) | 1 | |
| 3302172 | 47 FITTING-FUEL (WITH FILTER) | 1 |
