248-0901 BATTERY & WIRING GPS/N DBZ1-909

Group No: 248-0901

Part Number	Part Name	Qty
5T3907	1 CLAMP	2
6G2263	2 SPACER (10.5X19X28.5-MM THK)	1
8W0301	3 FLANGE	1
9G2758	4 LOCKOUT-SWITCH (BATTERY DISCONNECT)	1
2306368	5 BATTERY (12-VOLT, MAINTENANCE FREE, WET)	2
2368017	6 CABLE AS	1
1S7251	TERMINAL-CABLE (00-GA, 1/2-IN SCREW)	1
3S6051	TERMINAL AS (POSITIVE)	1
1M6119	BOLT (5/16-18X1.375-IN)	1
1M6120	NUT (5/16-18-THD)	1
1598049	CABLE (00-GA, RED)(100-CM)
7T9987	COVER AS-TERMINAL (RED)	1
8N0869	COVER-TERMINAL (RED)	1
2368018	7 CABLE AS	1
1S7251	TERMINAL-CABLE (00-GA, 1/2-IN SCREW)	2
1598049	CABLE (00-GA, RED)(301-CM)
8N0869	COVER-TERMINAL (RED)	2
2368019	8 CABLE AS	1
1S7251	TERMINAL-CABLE (00-GA, 1/2-IN SCREW)	2
1598050	CABLE (00-GA, BLACK)(58-CM)
9G8909	COVER-TERMINAL (BLACK)	2
2370982	9 CABLE AS	1
5P0761	CABLE (00-GA, RED)(22-CM)
9G0003	COVER AS-TERMINAL (BLACK)	1
9G0004	COVER AS-TERMINAL (RED)	1
8C5917	TERMINAL AS-BATTERY (POSITIVE)	1
1M6119	BOLT (5/16-18X1.375-IN)	1
1M6120	NUT (5/16-18-THD)	1
8T9757	TERMINAL AS-BATTERY (NEGATIVE)	1
1M6119	BOLT (5/16-18X1.375-IN)	1
1M6120	NUT (5/16-18-THD)	1
2377602	10 SWITCH GP-DISCONNECT (BATTERY)	1
2490103	11 HOLD-DOWN AS	1
2869678	12 CABLE AS	1
1S7251	TERMINAL-CABLE (00-GA, 1/2-IN SCREW)	1
5P0747	CABLE (00-GA, BLACK)(90-CM)
7N5274	COVER AS-TERMINAL (BLACK)	1
9G8909	COVER-TERMINAL (BLACK)	1
3S6050	TERMINAL AS-BATTERY (NEGATIVE)	1
1M6119	BOLT (5/16-18X1.375-IN)	1
1M6120	NUT (5/16-18-THD)	1
1505311	13 LOCKWASHER	6
1745907	14 CLIP	8
1P1210	15 WASHER (0.391X0.812X0.067-IN THK)	2
5M3062	16 BOLT (3/8-16X0.75-IN)	6
5P1075	17 WASHER-HARD (10.2X22.5X3-MM THK)	2
5P8167	18 BOLT (3/8-16X0.625-IN)	2
5S7379	19 BOLT (3/8-16X0.875-IN)	1
7K1181	20 STRAP-CABLE	7
7X0291	21 BOLT (3/8-16X3.75-IN)	2
8T4192	22 BOLT (M12X1.75X25-MM)	3
8T4223	23 WASHER-HARD (13.5X25.5X3-MM THK)	3
8T4896	24 WASHER-HARD (10.2X18.5X2.5-MM THK)	8
8T9377	25 BOLT (3/8-16X2.25-IN)	1
9M8406	26 CLIP (LOOP)	1
9X0941	27 LOCKNUT (1/2-13-THD)	3
