System And Components
248-0901 BATTERY & WIRING GPS/N DBZ910-922
Group No: 248-0901
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 10 | |
| 5T3907 | 2 CLAMP | 2 | |
| 6G2263 | 3 SPACER (10.5X19X28.5-MM THK) | 1 | |
| 8W0301 | 4 FLANGE | 1 | |
| 9G2758 | 5 LOCKOUT-SWITCH (BATTERY DISCONNECT) | 1 | |
| 1111374 | 6 BRACKET | 1 | |
| 2306368 | 7 BATTERY (12-VOLT, MAINTENANCE FREE, WET) | 2 | |
| 2368019 | 8 CABLE AS | 1 | |
| 1S7251 | TERMINAL-CABLE (00-GA, 1/2-IN SCREW) | 2 | |
| 1598050 | CABLE (00-GA, BLACK)(58-CM) | ||
| 9G8909 | COVER-TERMINAL (BLACK) | 2 | |
| 2370982 | 9 CABLE AS | 1 | |
| 5P0761 | CABLE (00-GA, RED)(22-CM) | ||
| 9G0003 | COVER AS-TERMINAL (BLACK) | 1 | |
| 9G0004 | COVER AS-TERMINAL (RED) | 1 | |
| 8C5917 | TERMINAL AS-BATTERY (POSITIVE) | 1 | |
| 1M6119 | BOLT (5/16-18X1.375-IN) | 1 | |
| 1M6120 | NUT (5/16-18-THD) | 1 | |
| 8T9757 | TERMINAL AS-BATTERY (NEGATIVE) | 1 | |
| 1M6119 | BOLT (5/16-18X1.375-IN) | 1 | |
| 1M6120 | NUT (5/16-18-THD) | 1 | |
| 2377602 | 10 SWITCH GP-DISCONNECT (BATTERY) | 1 | |
| 2490103 | 11 HOLD-DOWN AS | 1 | |
| 3109251 | 12 CABLE AS | 1 | |
| 1S7251 | TERMINAL-CABLE (00-GA, 1/2-IN SCREW) | 1 | |
| 9G0003 | COVER AS-TERMINAL (BLACK) | 1 | |
| 8L8413 | STRAP-CABLE (WHITE) | 1 | |
| 9G8909 | COVER-TERMINAL (BLACK) | 1 | |
| 9W3723 | TERMINAL AS-BATTERY (NEGATIVE) | 1 | |
| 1M6119 | BOLT (5/16-18X1.375-IN) | 1 | |
| 1M6120 | NUT (5/16-18-THD) | 1 | |
| 8T9757 | TERMINAL AS-BATTERY (NEGATIVE) | 1 | |
| 1598050 | CABLE (00-GA, BLACK)(99-CM) | ||
| 3124602 | 13 CABLE AS | 1 | |
| 1S7251 | TERMINAL-CABLE (00-GA, 1/2-IN SCREW) | 1 | |
| 8N1725 | COVER AS-TERMINAL (RED) | 1 | |
| 8L8413 | STRAP-CABLE (WHITE) | 1 | |
| 8T8827 | BOOT (RED) | 1 | |
| 9W3460 | TERMINAL AS-BATTERY (POSITIVE) | 1 | |
| 3S6049 | TERMINAL AS-BATTERY (POSITIVE) | 1 | |
| 1M6119 | BOLT (5/16-18X1.375-IN) | 1 | |
| 1M6120 | NUT (5/16-18-THD) | 1 | |
| 1598049 | CABLE (00-GA, RED)(127-CM) | ||
| 3124604 | 14 CABLE AS | 1 | |
| 1S7251 | TERMINAL-CABLE (00-GA, 1/2-IN SCREW) | 2 | |
| 8N0869 | COVER-TERMINAL (RED) | 1 | |
| 8T8827 | BOOT (RED) | 1 | |
| 1598049 | CABLE (00-GA, RED)(289-CM) | ||
| 1745907 | 15 CLIP | 10 | |
| 2V1771 | 16 GROMMET | 2 | |
| 2W7940 | 17 BRACKET | 1 | |
| 4L6454 | 18 BOLT (3/8-16X1-IN) | 2 | |
| 5M3062 | 19 BOLT (3/8-16X0.75-IN) | 6 | |
| 5P1075 | 20 WASHER-HARD (10.2X22.5X3-MM THK) | 4 | |
| 5P4295 | 21 CLIP | 1 | |
| 5P8167 | 22 BOLT (3/8-16X0.625-IN) | 2 | |
| 5S7379 | 23 BOLT (3/8-16X0.875-IN) | 1 | |
| 6D4246 | 24 CLIP (LOOP) | 1 | |
| 6V8801 | 25 NUT (3/8-16-THD) | 2 | |
| 7X0291 | 26 BOLT (3/8-16X3.75-IN) | 2 | |
| 8T4123 | 27 WASHER (22X35X3.5-MM THK) | 1 | |
| 8T4192 | 28 BOLT (M12X1.75X25-MM) | 4 | |
| 8T4223 | 29 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 8T4896 | 30 WASHER-HARD (10.2X18.5X2.5-MM THK) | 12 | |
| 8T9377 | 31 BOLT (3/8-16X2.25-IN) | 1 | |
| 9X0941 | 32 LOCKNUT (1/2-13-THD) | 4 |
