System And Components
248-0901 BATTERY & WIRING GPS/N DBZ923-UP
Group No: 248-0901
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 16 | |
| 5T3907 | 2 CLAMP | 2 | |
| 6G2263 | 3 SPACER (10.5X19X28.5-MM THK) | 1 | |
| 8W0301 | 4 FLANGE | 1 | |
| 9G2758 | 5 LOCKOUT-SWITCH (BATTERY DISCONNECT) | 1 | |
| 1706929 | 6 CABLE AS | 2 | |
| 9G0002 | COVER AS-TERMINAL (RED) | 1 | |
| 9G0005 | COVER AS-TERMINAL (BLACK) | 1 | |
| 5P0761 | CABLE (00-GA, RED)(31-CM) | ||
| 8C5918 | TERMINAL AS-BATTERY (NEGATIVE) | 1 | |
| 8T9756 | TERMINAL AS-BATTERY (POSITIVE) | 1 | |
| 1M6119 | BOLT (5/16-18X1.375-IN) | 1 | |
| 1M6120 | NUT (5/16-18-THD) | 1 | |
| 2286969 | 7 CABLE AS | 1 | |
| 1S7251 | TERMINAL-CABLE (00-GA, 1/2-IN SCREW) | 1 | |
| 7T4924 | COVER-TERMINAL (RED) | 1 | |
| 8N0869 | COVER-TERMINAL (RED) | 1 | |
| 9G0002 | COVER AS-TERMINAL (RED) | 1 | |
| 1598049 | CABLE (00-GA, RED)(129-CM) | ||
| 9S5754 | TERMINAL AS-BATTERY (POSITIVE) | 1 | |
| 8T9756 | TERMINAL AS-BATTERY (POSITIVE) | 1 | |
| 1M6119 | BOLT (5/16-18X1.375-IN) | 1 | |
| 1M6120 | NUT (5/16-18-THD) | 1 | |
| 2306368 | 8 BATTERY (12-VOLT, MAINTENANCE FREE, WET) | 4 | |
| 2368019 | 9 CABLE AS | 1 | |
| 1S7251 | TERMINAL-CABLE (00-GA, 1/2-IN SCREW) | 2 | |
| 1598050 | CABLE (00-GA, BLACK)(58-CM) | ||
| 9G8909 | COVER-TERMINAL (BLACK) | 2 | |
| 2377602 | 10 SWITCH GP-DISCONNECT (BATTERY) | 1 | |
| 2490103 | 11 HOLD-DOWN AS | 1 | |
| 2899519 | 12 BRACKET | 2 | |
| 3124604 | 13 CABLE AS | 1 | |
| 1S7251 | TERMINAL-CABLE (00-GA, 1/2-IN SCREW) | 2 | |
| 8N0869 | COVER-TERMINAL (RED) | 1 | |
| 8T8827 | BOOT (RED) | 1 | |
| 1598049 | CABLE (00-GA, RED)(289-CM) | ||
| 3124605 | 14 CABLE AS | 1 | |
| 1S7251 | TERMINAL-CABLE (00-GA, 1/2-IN SCREW) | 1 | |
| 7N5274 | COVER AS-TERMINAL (BLACK) | 1 | |
| 7T4925 | COVER-TERMINAL (BLACK) | 1 | |
| 9G8909 | COVER-TERMINAL (BLACK) | 1 | |
| 1598050 | CABLE (00-GA, BLACK)(110-CM) | ||
| 9S5755 | TERMINAL AS (NEGATIVE) | 1 | |
| 3S6050 | TERMINAL AS-BATTERY (NEGATIVE) | 1 | |
| 1M6119 | BOLT (5/16-18X1.375-IN) | 1 | |
| 1M6120 | NUT (5/16-18-THD) | 1 | |
| 1327551 | 15 SPACER (11X19X6-MM THK) | 1 | |
| 1745907 | 16 CLIP | 2 | |
| 2V1771 | 17 GROMMET | 11 | |
| 4L6454 | 18 BOLT (3/8-16X1-IN) | 3 | |
| 5M3062 | 19 BOLT (3/8-16X0.75-IN) | 5 | |
| 5P1075 | 20 WASHER-HARD (10.2X22.5X3-MM THK) | 8 | |
| 5P4295 | 21 CLIP | 1 | |
| 5P4325 | 22 CLIP (LOOP) | 1 | |
| 5P8167 | 23 BOLT (3/8-16X0.625-IN) | 2 | |
| 5S7379 | 24 BOLT (3/8-16X0.875-IN) | 1 | |
| 6D4246 | 25 CLIP (LOOP) | 10 | |
| 6V8801 | 26 NUT (3/8-16-THD) | 3 | |
| 7X0291 | 27 BOLT (3/8-16X3.75-IN) | 2 | |
| 8T4123 | 28 WASHER (22X35X3.5-MM THK) | 1 | |
| 8T4192 | 29 BOLT (M12X1.75X25-MM) | 4 | |
| 8T4223 | 30 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 8T4896 | 31 WASHER-HARD (10.2X18.5X2.5-MM THK) | 10 | |
| 8T9377 | 32 BOLT (3/8-16X2.25-IN) | 1 | |
| 9B7237 | 33 BOLT (3/8-16X1.25-IN) | 1 | |
| 9X0941 | 34 LOCKNUT (1/2-13-THD) | 4 |
