System And Components
228-6886 WIRING GP-SCRAPERS/N DBZ905-UP
Group No: 228-6886
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5N2126 | 1 CONNECTOR (THERMOCOUPLE) | 1 | |
| 6V4283 | 2 PLATE-IDENTIFICATION (ALTERNATOR RESET) | 1 | |
| 7K1181 | 3 STRAP-CABLE | 31 | |
| 0960192 | 4 LOCKWASHER | 2 | |
| 9X3271 | 5 ADAPTER (1/2-14-THD) | 1 | |
| 1251302 | 6 SWITCH GP-MAGNETIC (24-VOLT)(START RELAY) | 1 | |
| 1256390 | 7 PLATE-INFORMATION (ENGINE) | 3 | |
| 1310427 | 8 SENSOR GP-TEMPERATURE (TORQUE CONVERTER OIL) | 1 | |
| 1619926 | 9 SENSOR GP-PRESSURE (TURBOCHARGER INLET) | 1 | |
| 1655970 | 10 SWITCH GP-TOGGLE (FUEL PRIMING PUMP) | 1 | |
| 1712206 | 11 CIRCUIT BREAKER AS (50-AMPERE)(ALTERNATOR) | 1 | |
| 6V8187 | NUT (1/4-28-THD) | 2 | |
| 8T4205 | WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 2532111 | LOCKWASHER | 2 | |
| 1753687 | 12 BRACKET AS | 1 | |
| 9X2032 | NUT-WELD (M4X0.7-THD) | 4 | |
| 1806356 | 13 BRACKET | 1 | |
| 2042281 | 14 STRAP-CABLE | 4 | |
| 2005332 | 15 PLATE AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 5 | |
| 9F6445 | NUT-WELD (1/4-20-THD) | 4 | |
| 2005335 | 16 COVER | 1 | |
| 2048000 | 17 MOUNTING-CABLE TIE | 4 | |
| 2055399 | 18 HARNESS AS-BOX | 1 | |
| 2197224 | 19 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 2286892 | 20 HARNESS AS-TRANSMISSION | 1 | |
| 2286973 | 21 HARNESS AS-ENGINE (REAR) | 1 | |
| 2905562 | 22 MOUNT (DUAL SWIVEL) | 1 | |
| 3352426 | 23 WIRE AS | 1 | |
| 1148843 | SLEEVE-PLASTIC (10-CM) | ||
| 0338248 | 24 CLIP (LOOP) | 1 | |
| 1241479 | 25 CLIP (LOOP) | 2 | |
| 1305300 | 26 CLIP | 5 | |
| 1325789 | 27 CLIP (LADDER) | 1 | |
| 1470385 | 28 CLIP | 1 | |
| 1H4393 | 29 LOCKWASHER | 6 | |
| 1S0994 | 30 CLIP (LOOP) | 2 | |
| 2S9556 | 31 SCREW-MACHINE (10-32X0.875-IN) | 2 | |
| 3E5239 | 32 RELAY AS (24-VOLT)(TRANSMISSION) | 1 | |
| 3J1907 | 33 SEAL-O-RING | 1 | |
| 3J7354 | 34 SEAL-O-RING | 1 | |
| 4D7794 | 35 CLIP | 2 | |
| 4D9517 | 36 CLIP | 1 | |
| 4K8864 | 37 CLIP (LOOP) | 7 | |
| 4L6454 | 38 BOLT (3/8-16X1-IN) | 3 | |
| 4P7581 | 39 CLIP (LADDER) | 5 | |
| 4P8134 | 40 CLIP (LADDER) | 3 | |
| 4S1962 | 41 CLIP (LOOP) | 2 | |
| 5M3062 | 42 BOLT (3/8-16X0.75-IN) | 27 | |
| 5S7349 | 43 BOLT (1/4-20X0.5-IN) | 3 | |
| 5S7379 | 44 BOLT (3/8-16X0.875-IN) | 4 | |
| 6D4244 | 45 CLIP (LOOP) | 1 | |
| 6T3642 | 46 CIRCUIT BREAKER AS (10-AMPERE)(TRANSMISSION) | 1 | |
| 6T3643 | 47 CIRCUIT BREAKER AS (15-AMPERE)(ENGINE CONTROL) | 1 | |
| 6T3643 | 47A CIRCUIT BREAKER AS (15-AMPERE)(MAIN POWER) | 1 | |
| 6V8376 | SCREW-MACHINE (8-32X0.25-IN) | 2 | |
| 9B7233 | LOCKWASHER | 2 | |
| 6V7345 | 48 SCREW-MACHINE (8-32X0.875-IN) | 6 | |
| 6V8801 | 49 NUT (3/8-16-THD) | 1 | |
| 7B9919 | 50 CLIP | 1 | |
| 8T4189 | 51 BOLT (M8X1.25X20-MM) | 2 | |
| 8T4205 | 52 WASHER-HARD (7.2X14.5X2-MM THK) | 3 | |
| 8T4896 | 53 WASHER-HARD (10.2X18.5X2.5-MM THK) | 39 | |
| 8T9405 | 54 BOLT-SOCKET HEAD (M4X0.7X16-MM) | 4 | |
| 9B7237 | 55 BOLT (3/8-16X1.25-IN) | 2 | |
| 9X8250 | 56 CLIP (LOOP) | 2 | |
| 5P6029 | 57 LOCKWIRE (0.2-M) |
