System And Components
228-6886 WIRING GP-SCRAPERS/N DBZ947-UP
Group No: 228-6886
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 2 | |
| 6V4283 | 2 PLATE-IDENTIFICATION (ALTERNATOR RESET) | 1 | |
| 6V9601 | 3 ADAPTER | 1 | |
| 6W6672 | 4 SPACER (10.5X20X38-MM THK) | 1 | |
| 7K1181 | 5 STRAP-CABLE | 30 | |
| 0960192 | 6 LOCKWASHER | 6 | |
| 9X3271 | 7 ADAPTER (1/2-14-THD) | 1 | |
| 1251302 | 8 SWITCH GP-MAGNETIC (24-VOLT)(START RELAY) | 1 | |
| 1655970 | 9 SWITCH GP-TOGGLE (FUEL PRIMING PUMP) | 1 | |
| 1712208 | 10 CIRCUIT BREAKER AS (60-AMPERE)(ALTERNATOR) | 1 | |
| 1H3244 | LOCKWASHER | 2 | |
| 4E5724 | WASHER (7X12X1-MM THK) | 2 | |
| 8T0122 | NUT-FULL (1/4-28-THD) | 2 | |
| 1731583 | 11 BRACKET AS | 1 | |
| 1753687 | 12 BRACKET AS | 1 | |
| 9X2032 | NUT-WELD (M4X0.7-THD) | 4 | |
| 2042281 | 13 STRAP-CABLE | 17 | |
| 2252607 | 14 PLATE | 1 | |
| 2286892 | 15 HARNESS AS-TRANSMISSION | 1 | |
| 2048000 | 16 MOUNTING-CABLE TIE | 14 | |
| 2746717 | 17 SENSOR-PRESSURE (TURBOCHARGER INLET) | 1 | |
| 3070294 | 18 BAR-BUS | 1 | |
| 3352426 | 19 WIRE AS | 1 | |
| 3412687 | 20 PLATE | 1 | |
| 3668931 | 21 PANEL AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 4 | |
| 9F6445 | NUT-WELD (1/4-20-THD) | 2 | |
| 3668934 | 22 COVER | 1 | |
| 3677604 | 23 FILM-IDENTIFICATION (FUSE, RELAY PANEL) | 1 | |
| 3707277 | 24 HARNESS AS-ENGINE (REAR) | 1 | |
| 1138373 | 25 SCREW-BUTTON HEAD (10-32X0.75-IN) | 6 | |
| 1305300 | 26 CLIP | 5 | |
| 1325789 | 27 CLIP (LADDER) | 7 | |
| 1342252 | 28 SENSOR GP-TEMPERATURE (8-VOLT)(TORQUE CONVERTER OIL) | 1 | |
| 3J1907 | 29 SEAL-O-RING | 2 | |
| 4L6454 | 30 BOLT (3/8-16X1-IN) | 5 | |
| 4M5281 | 31 BOLT (1/4-20X0.75-IN) | 2 | |
| 4P7581 | 32 CLIP (LADDER) | 10 | |
| 4P8134 | 33 CLIP (LADDER) | 2 | |
| 3445673 | 34 NUT (M6X1-THD) | 1 | |
| 5M3062 | 35 BOLT (3/8-16X0.75-IN) | 13 | |
| 5P4116 | 36 WASHER-HARD (8.8X20.5X2-MM THK) | 1 | |
| 5S7379 | 37 BOLT (3/8-16X0.875-IN) | 9 | |
| 5S7382 | 38 BOLT (3/8-16X1.375-IN) | 1 | |
| 6V8801 | 39 NUT (3/8-16-THD) | 1 | |
| 1H3244 | 40 LOCKWASHER | 1 | |
| 8T4121 | 41 WASHER-HARD (11X21X2.5-MM THK) | 3 | |
| 8T4136 | 42 BOLT (M10X1.5X25-MM) | 1 | |
| 8T4137 | 43 BOLT (M10X1.5X20-MM) | 1 | |
| 8T4189 | 44 BOLT (M8X1.25X20-MM) | 1 | |
| 8T4205 | 45 WASHER-HARD (7.2X14.5X2-MM THK) | 3 | |
| 8T4896 | 46 WASHER-HARD (10.2X18.5X2.5-MM THK) | 33 | |
| 8T5005 | 47 BOLT (M10X1.5X70-MM) | 1 | |
| 8T9405 | 48 BOLT-SOCKET HEAD (M4X0.7X16-MM) | 4 | |
| 9B7237 | 49 BOLT (3/8-16X1.25-IN) | 4 | |
| 5P6029 | 50 LOCKWIRE (0.2-M) | ||
| 4254513 | 51 RETAINER | 1 |
