System And Components
263-2931 LINES GP-POWER TRAIN OILS/N DBZ1-676
Group No: 263-2931
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2D5248 | 1 GASKET | 1 | |
| 3N7361 | 2 HOSE AS | 1 | |
| 5D7524 | 3 HOSE AS | 1 | |
| 6D8465 | 4 SUMP | 1 | |
| 6D8500 | 5 RETAINER | 1 | |
| 6D8669 | 6 TUBE AS | 1 | |
| 6D8736 | 7 TUBE AS | 1 | |
| 6G0078 | 8 BREATHER (TRANSMISSION) | 1 | |
| 7D4777 | 9 SCREEN AS (TRANSMISSION) | 1 | |
| 7X7958 | 10 CLAMP-HOSE | 4 | |
| 8C3447 | 11 CAP-DUST | 1 | |
| 8R9762 | 12 HOSE AS | 1 | |
| 8T6703 | 13 CLAMP-HOSE | 4 | |
| 8W0289 | 14 ADAPTER | 1 | |
| 0520726 | 15 TEE | 1 | |
| 1357902 | 16 HOSE AS | 1 | |
| 8C3446 | 17 VALVE-SAMPLING | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 1988543 | 18 TUBE AS | 1 | |
| 1988549 | 19 TUBE AS | 1 | |
| 1988552 | 20 TUBE AS | 1 | |
| 1988554 | 21 TUBE AS | 1 | |
| 1994982 | 22 PLATE | 1 | |
| 2064669 | 23 VALVE-DRAIN | 1 | |
| 2632934 | 24 HOSE AS | 1 | |
| 2632935 | 25 TUBE AS | 1 | |
| 2632936 | 26 TUBE AS | 1 | |
| 2632938 | 27 PLATE AS | 1 | |
| 2632939 | 28 HOSE AS | 1 | |
| 2632940 | 29 HOSE AS | 1 | |
| 0026453 | 30 ELBOW | 1 | |
| 1488327 | 31 CONNECTOR AS | 1 | |
| 6V8637 | CONNECTOR | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488347 | 32 ELBOW AS | 1 | |
| 6V9007 | ELBOW | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488388 | 33 ELBOW AS | 1 | |
| 6V8629 | ELBOW | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1626802 | 34 ELBOW AS | 1 | |
| 1515145 | ELBOW | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 1H7339 | 35 SEAL-O-RING | 1 | |
| 1P3705 | 36 SEAL-RECTANGULAR | 2 | |
| 1P4577 | 37 FLANGE-HALF | 6 | |
| 1P4578 | 38 FLANGE-HALF | 4 | |
| 2H3940 | 39 ELBOW | 1 | |
| 3J5390 | 40 PLUG (3/8-18-THD) | 1 | |
| 4D7388 | 41 CLIP | 1 | |
| 4J0522 | 42 SEAL-O-RING | 2 | |
| 4L6454 | 43 BOLT (3/8-16X1-IN) | 7 | |
| 5F8000 | 44 SEAL-O-RING | 2 | |
| 5M3062 | 45 BOLT (3/8-16X0.75-IN) | 4 | |
| 5P1075 | 46 WASHER-HARD (10.2X22.5X3-MM THK) | 3 | |
| 5P2424 | 47 BOLT (1/2-13X2.25-IN) | 4 | |
| 5S7382 | 48 BOLT (3/8-16X1.375-IN) | 12 | |
| 6D4733 | 49 GASKET | 1 | |
| 7D0702 | 50 CONNECTOR | 1 | |
| 7X0328 | 51 BOLT (1/2-13X3.5-IN) | 4 | |
| 8M4987 | 52 SEAL-O-RING | 6 | |
| 8M5010 | 53 SEAL-O-RING | 2 | |
| 8M5661 | 54 SEAL-O-RING | 1 | |
| 8S0023 | 55 CLIP (SLOT) | 2 | |
| 8S0024 | 56 CLIP (TAB) | 2 | |
| 8T2502 | 57 BOLT (3/8-16X1.125-IN) | 2 | |
| 8T4121 | 58 WASHER-HARD (11X21X2.5-MM THK) | 1 | |
| 8T4136 | 59 BOLT (M10X1.5X25-MM) | 1 | |
| 8T4223 | 60 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 8T4896 | 61 WASHER-HARD (10.2X18.5X2.5-MM THK) | 34 | |
| 8T5360 | 62 WASHER (12X22.5X2.5-MM THK) | 8 | |
| 8T8916 | 63 BOLT (7/16-14X1.5-IN) | 8 | |
| 9B7237 | 64 BOLT (3/8-16X1.25-IN) | 12 | |
| 5P2094 | 65 HOSE (13-CM) | ||
| 5P1292 | 66 HOSE (18-CM EACH) | 2 |
