System And Components
9G-0953 PLANETARY GP-TRANSMISSIONS/N CWK1-UP; DRX1-UP
Group No: 9G-0953
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9G0958 | 1 HOUSING AS-CLUTCH | 1 | |
| 4B9782 | BALL | 2 | |
| 9G0333 | 2 SEAL-RING | 1 | |
| 9G0339 | 3 PISTON-CLUTCH | 1 | |
| 1028671 | 4 DISC-FRICTION | 4 | |
| 7G0825 | 5 PLATE-CLUTCH | 5 | |
| 9G0959 | 6 HOUSING AS-CLUTCH | 1 | |
| 5M7937 | DOWEL | 4 | |
| 4B9782 | BALL | 2 | |
| 5M5018 | 7 BEARING-ROLLER | 3 | |
| 5S7859 | 8 SHAFT-PLANETARY | 3 | |
| 9G0325 | 9 PISTON-CLUTCH | 2 | |
| 9G0326 | 10 GEAR-RING (81-TEETH) | 1 | |
| 5M2051 | 11 BEARING-CAGED | 9 | |
| 9G0330 | 12 GEAR-PLANETARY (26-TEETH) | 6 | |
| 9G0329 | 13 GEAR-RING (81-TEETH) | 1 | |
| 9G0957 | 14 HOUSING AS-CLUTCH | 1 | |
| 2D6642 | BALL | 2 | |
| 9G0956 | 15 PLATE AS-CENTER | 1 | |
| 7M1201 | DOWEL | 2 | |
| 8E8307 | 16 DISC-THRUST | 18 | |
| 9G0322 | 17 HOUSING-CLUTCH | 1 | |
| 7G3464 | 18 GEAR-PLANETARY (21-TEETH) | 3 | |
| 9G0332 | 19 GEAR-RING (70-TEETH) | 1 | |
| 9G0338 | 20 PISTON-CLUTCH | 1 | |
| 3S2708 | 21 PIN-SPRING | 9 | |
| 9G0335 | 22 SEAL-RING | 1 | |
| 5F1678 | 23 SEAL-O-RING | 1 | |
| 8S3492 | 24 MANIFOLD-SEAL | 1 | |
| 6P5771 | 25 MANIFOLD AS | 1 | |
| 4B9782 | BALL | 2 | |
| 5P8245 | 26 WASHER-HARD (13.5X25.5X3-MM THK) | 16 | |
| 2S8926 | 27 BOLT (1/2-13X13.375-IN) | 12 | |
| 8E2477 | 28 DISC-FRICTION | 5 | |
| 3P2792 | 29 SEAL-RING | 1 | |
| 3P2768 | 30 PISTON-CLUTCH | 1 | |
| 3708592 | 31 PLATE-CLUTCH | 3 | |
| 6I9255 | 32 DISC-FRICTION | 4 | |
| 5M2894 | 33 WASHER-HARD (10.2X18.5X2.5-MM THK) | 32 | |
| 0T0065 | 34 BOLT (3/8-16X3.5-IN) | 20 | |
| 1P9261 | 35 SEAL-RING | 1 | |
| 3T9165 | 36 SPRING-DISC | 3 | |
| 1T0416 | 37 BOLT (5/16-18X0.75-IN) | 8 | |
| 3T9166 | 38 PLATE-RETAINER | 1 | |
| 9M2095 | 39 RING-RETAINING | 2 | |
| 9G0319 | 40 CAGE-BEARING | 1 | |
| 3K2518 | 41 BALL BEARING | 1 | |
| 1T0479 | 42 RING-RETAINING | 1 | |
| 4S6712 | 43 RING-RETAINING | 2 | |
| 9G0340 | 44 SHAFT-OUTPUT | 1 | |
| 5M3406 | 45 RING-RETAINING | 1 | |
| 3T9168 | 46 RETAINER AS | 1 | |
| 6K4936 | 47 BOLT-LOCKING (3/8-16X0.625-IN) | 6 | |
| 9G0316 | 48 HUB | 1 | |
| 6Y5793 | 49 RING-SEAL | 2 | |
| 8S3517 | 50 BALL BEARING | 1 | |
| 9G0317 | 51 PLATE | 1 | |
| 9G0955 | 52 HOUSING AS | 1 | |
| 8B1312 | DOWEL | 3 | |
| 2P2913 | 53 RING-RETAINING | 1 | |
| 9M1503 | 54 RING-METAL SEAL | 1 | |
| 5K9107 | 55 BOLT-LOCKING (3/8-16X0.75-IN) | 18 | |
| 4M2442 | 56 BOLT (1/2-13X12.32-IN) | 4 | |
| 6P6739 | 57 SHAFT-PLANETARY | 3 | |
| 8E8304 | 58 DISC-THRUST | 12 | |
| 7G3465 | 59 GEAR-PLANETARY (18-TEETH) | 3 | |
| 5M6126 | 60 BEARING AS-ROLLER | 3 | |
| 4M5016 | 61 SPRING | 10 | |
| 3P8014 | 62 GEAR-SUN (25-TEETH) | 1 | |
| 9G0328 | 63 GEAR-SUN (30-TEETH) | 1 | |
| 6P3149 | 64 CARRIER-PLANETARY | 1 | |
| 4M7092 | 65 RING-RETAINING | 1 | |
| 9G0954 | 66 GEAR AS (30-TEETH) | 1 | |
| 9M2001 | DOWEL | 1 | |
| 4M9592 | 67 SPRING | 20 | |
| 1S5623 | 68 PLATE-LOCK | 3 | |
| 3K2510 | 69 DOWEL-REACTION | 5 | |
| 8P8744 | 70 RING-SEAL EXTENSION | 3 | |
| 8P9569 | 71 RING-SEAL | 2 | |
| 9M4335 | 72 DOWEL-REACTION | 5 | |
| 9G0331 | 73 GEAR-RING (101-TEETH) | 1 | |
| 8S3448 | 74 CARRIER-PLANETARY | 1 | |
| 3K2556 | 75 RING-RETAINING | 2 | |
| 8S3465 | 76 GEAR-SUN (55-TEETH) | 1 | |
| 1M4169 | 77 RING-METAL SEAL | 1 | |
| 1M4093 | 78 RING-RETAINING | 2 | |
| 6F0155 | 79 RING-METAL SEAL | 1 | |
| 7S3002 | 80 BALL BEARING | 2 | |
| 8S3464 | 81 CAGE-BEARING | 1 | |
| 8S3456 | 82 MANIFOLD AS | 1 | |
| 9M2001 | DOWEL | 1 | |
| 1A2029 | 83 BOLT (3/8-16X1.125-IN) | 6 | |
| 2S4900 | 84 SHAFT AS | 3 | |
| 3S0036 | PLUG-CORE | 1 | |
| 2S4899 | SHAFT-PLANETARY | 1 | |
| 7G2501 | 85 GEAR-PLANETARY (24-TEETH) | 3 | |
| 9G0334 | 86 RING-SEAL | 1 | |
| 9M4355 | 87 DAMPER-BOLT | 16 | |
| 9G0960 | 88 HOUSING AS | 1 | |
| 6B6863 | PIN-SPRING | 1 | |
| 4S8537 | DOWEL | 1 | |
| 6P7705 | CARRIER-RING | 1 |
