System And Components
234-7894 GUARD GP-RADIATORS/N DBZ1-UP
Group No: 234-7894
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1S4305 | 1 SPACER (0.531X1X0.56-IN THK) | 4 | |
| 5T3523 | 2 BRACE AS | 1 | |
| 5D8060 | END-RADIATOR BRACE | 2 | |
| 5D9629 | ROD | 1 | |
| 7V6064 | 3 BOLT AS | 14 | |
| 1998043 | 4 COVER AS | 1 | |
| 2231455 | 5 BRACE AS | 1 | |
| 5D8060 | END-RADIATOR BRACE | 2 | |
| 5D9629 | ROD | 1 | |
| 2424046 | 6 GUARD GP-RADIATOR | 1 | |
| 1F0748 | NUT-WELD (1/2-13-THD) | 2 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 4 | |
| 2601436 | BRACKET AS | 1 | |
| 4M7406 | GUSSET | 3 | |
| 2424047 | 7 GUARD GP-RADIATOR | 1 | |
| 1F0748 | NUT-WELD (1/2-13-THD) | 2 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 4 | |
| 4M7406 | GUSSET | 3 | |
| 4V7412 | BOSS (3/8-16-THD) | 4 | |
| 2601436 | BRACKET AS | 1 | |
| 2424051 | 8 GUARD GP-RADIATOR | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 10 | |
| 3F7851 | LUG | 4 | |
| 4V7412 | BOSS (3/8-16-THD) | 1 | |
| 9F6445 | NUT-WELD (1/4-20-THD) | 4 | |
| 9M5732 | RIVET-POP | 9 | |
| 2007925 | STRIP | 1 | |
| 2452968 | 9 GRILL AS | 1 | |
| 4L6454 | 10 BOLT (3/8-16X1-IN) | 1 | |
| 2462641 | 11 PADLOCK GP (RADIATOR GUARD) | 1 | |
| 5P8500 | KEY | 1 | |
| 8T4223 | 12 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 8T4896 | 13 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 8T8919 | 14 BOLT (1/2-13X1.75-IN) | 12 |
