System And Components
272-2587 STEP GPS/N DBZ1-UP
Group No: 272-2587
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4V9803 | 1 PLATE | 4 | |
| 4V9804 | 2 PLATE | 2 | |
| 2671291 | 3 BRACKET | 1 | |
| 2671292 | 4 BRACKET | 1 | |
| 2671293 | 5 BRACKET AS | 1 | |
| 2671294 | 6 BRACKET AS | 1 | |
| 2672778 | 7 PLATE | 2 | |
| 2677539 | 8 SUPPORT-STEP (RUBBER) | 2 | |
| 2796074 | 9 STEP AS | 3 | |
| 4V9803 | PLATE | 2 | |
| 1B2709 | 10 BOLT-CARRIAGE (1/2-13X3.2-IN) | 4 | |
| 1D4687 | 11 BOLT-CARRIAGE | 4 | |
| 1D4688 | 12 BOLT (1/2-13X1.5-IN) | 4 | |
| 1D4690 | 14 BOLT-CARRIAGE (1/2-13X2.25-IN) | 6 | |
| 1K6872 | 15 LOCKNUT (1/2-13-THD) | 18 | |
| 5P1076 | 16 WASHER-HARD (13.5X30X4-MM THK) | 2 | |
| 8T4223 | 17 WASHER-HARD (13.5X25.5X3-MM THK) | 16 | |
| 3569931 | 18 SHAFT | 2 | |
| 2153579 | 19 SLEEVE | 4 |
