System And Components
5J-2450 CYLINDER GP-BOWL -LHS/N DBZ1-UP
Group No: 5J-2450
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3J9545 | 1 LOCKNUT (2-12-THD) | 1 | |
| 7J5326 | 2 RING-WEAR | 1 | |
| 5J4989 | 3 SEAL AS | 1 | |
| 9J8047 | 4 PISTON | 1 | |
| 9T3709 | 5 HEAD | 1 | |
| 1D4612 | 6 BOLT (3/4-10X4-IN) | 2 | |
| 5H1504 | 7 WASHER-HARD (20X33.5X5-MM THK) | 8 | |
| 5J0974 | 8 CYLINDER AS | 1 | |
| 5J2445 | 9 BUSHING | 1 | |
| 1672201 | 10 SEAL AS-BUFFER | 1 | |
| 5J2453 | 11 ROD AS-PISTON | 1 | |
| 5J2445 | 12 BUSHING | 1 | |
| 5H3252 | 13 SEAL-O-RING | 1 | |
| 1672463 | 14 SEAL-WIPER | 1 | |
| 1672312 | 15 SEAL-U-CUP | 1 | |
| 3B2968 | 16 BOLT (3/4-10X3.5-IN) | 6 | |
| 2K3258 | 17 RING-BACKUP | 1 | |
| 8T8365 | 18 RING-WEAR | 1 |
