System And Components
119-8449 LINES GP-AUGER MOTORS/N DBZ1-UP
Group No: 119-8449
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1242425 | 1 VALVE GP-FLUSHING (AUGER) | 1 | |
| 1P5767 | 2 FLANGE-HALF | 2 | |
| 7X0333 | 3 BOLT (1/2-13X4.75-IN) | 4 | |
| 8T4223 | 4 WASHER-HARD (13.5X25.5X3-MM THK) | 23 | |
| 1645624 | 5 ELBOW AS | 1 | |
| 9X2085 | ELBOW | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1488381 | 7 ELBOW AS | 1 | |
| 8T5429 | ELBOW | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 4T2958 | 9 HOSE AS | 1 | |
| 1251117 | 11 MANIFOLD | 1 | |
| 1P3704 | 12 SEAL-RECTANGULAR | 3 | |
| 5S2389 | 13 BOLT-SOCKET HEAD (1/2-13X2.75-IN) | 4 | |
| 1620177 | 14 PLUG AS | 1 | |
| 9S8004 | PLUG (9/16-18-THD) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 1645619 | 15 PLUG AS | 1 | |
| 9S8006 | PLUG (7/8-14-THD) | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 1P4577 | 17 FLANGE-HALF | 10 | |
| 9B7237 | 18 BOLT (3/8-16X1.25-IN) | 4 | |
| 8T4896 | 19 WASHER-HARD (10.2X18.5X2.5-MM THK) | 24 | |
| 1320905 | 20 HOSE AS | 1 | |
| 4J0522 | 21 SEAL-O-RING | 5 | |
| 1P4578 | 22 FLANGE-HALF | 12 | |
| 8T8916 | 23 BOLT (7/16-14X1.5-IN) | 24 | |
| 8T5360 | 24 WASHER (12X22.5X2.5-MM THK) | 24 | |
| 5H4020 | 25 COVER | 1 | |
| 1488324 | 26 CONNECTOR AS | 1 | |
| 6V9874 | CONNECTOR | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 6V9832 | 28 CAP (ORFS) | 1 | |
| 6V0852 | 31 CAP-DUST | 2 | |
| 7I5656 | 32 HOSE AS | 1 | |
| 8T2525 | 33 GROMMET | 1 | |
| 5P7468 | 34 CLIP (SLOT) | 2 | |
| 5P7469 | 35 CLIP (TAB) | 2 | |
| 8T8917 | 36 BOLT (1/2-13X1.25-IN) | 3 | |
| 1P3703 | 37 SEAL-RECTANGULAR | 3 | |
| 6V0400 | 38 FLANGE-HALF | 8 | |
| 8T4184 | 39 BOLT (M12X1.75X45-MM) | 16 | |
| 1468497 | 40 HOSE AS | 1 | |
| 5P8444 | 41 GROMMET (37-MM ID) | 1 | |
| 1488347 | 42 ELBOW AS | 1 | |
| 6V9007 | ELBOW | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1468499 | 43 HOSE AS | 1 | |
| 5P8112 | 44 GROMMET | 1 | |
| 5P7466 | 45 CLIP (SLOT) | 1 | |
| 5P7467 | 46 CLIP (TAB) | 1 | |
| 4J0520 | 47 SEAL-O-RING | 5 | |
| 5S7382 | 48 BOLT (3/8-16X1.375-IN) | 16 | |
| 2304531 | 49 TUBE AS | 1 | |
| 2304532 | 50 TUBE AS | 1 | |
| 2304533 | 51 TUBE AS | 1 | |
| 1412288 | 52 CLAMP | 2 | |
| 7X0332 | 53 BOLT (1/2-13X4.5-IN) | 2 | |
| 5P1076 | 54 WASHER-HARD (13.5X30X4-MM THK) | 8 | |
| 6V8188 | 55 NUT (1/2-13-THD) | 2 | |
| 1412289 | 56 CLAMP AS | 3 | |
| 6V8188 | NUT (1/2-13-THD) | 2 | |
| 1412290 | CLAMP | 1 | |
| 1412290 | 57 CLAMP | 3 | |
| 8B7979 | 58 BOLT (1/2-13X2.5-IN) | 2 | |
| 7X0328 | 59 BOLT (1/2-13X3.5-IN) | 4 | |
| 7I5657 | 60 HOSE AS | 1 | |
| 1468498 | 61 HOSE AS | 1 | |
| 7I5667 | 62 HOSE AS | 1 | |
| 1468493 | 63 TUBE AS | 1 | |
| 1468494 | 64 TUBE AS | 1 | |
| 1468495 | 65 TUBE AS | 1 | |
| 1412295 | 66 CHANNEL | 1 | |
| 1478206 | 67 BUSHING-SPLIT | 3 | |
| 1412292 | 68 BUSHING-SPLIT | 3 | |
| 1412293 | 69 BUSHING-SPLIT | 3 | |
| 1412294 | 70 CLAMP | 18 | |
| 1412250 | 71 NUT | 18 | |
| 4L6454 | 72 BOLT (3/8-16X1-IN) | 40 | |
| 5P1075 | 73 WASHER-HARD (10.2X22.5X3-MM THK) | 36 | |
| 2466011 | 74 PLATE AS | 2 | |
| 1645567 | 75 COUPLER AS-QUICK DISCONNECT (MALE) | 2 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 2301138 | 76 PLATE | 1 |
